Overview
Designed for demanding industrial environments, it delivers stable 15-bit resolution for accurate process control applications.
Moreover, the module integrates seamlessly with VersaMax and VersaPoint systems in compact automation architectures.
Engineers rely on this unit when consistent analog performance directly affects production quality and safety.The module supports both voltage and current signals, which simplifies configuration across mixed instrumentation systems.
Therefore, it reduces panel complexity while maintaining high signal integrity in distributed installations.
Specification
| Parameter | Specification |
|---|---|
| Product Model | IC220ALG220 |
| Product Type | VersaMax Analog Input Module |
| Analog Resolution | 15-bit |
| Input Signal Types | Voltage and Current |
| Typical Voltage Ranges | 0–10 V, ±10 V (configurable) |
| Typical Current Range | 4–20 mA |
| Number of Channels | 2 analog input channels |
| Isolation | Channel-to-bus isolation |
| Mounting | DIN-rail mounting |
| Backplane Compatibility | VersaMax / VersaPoint I/O systems |
| Diagnostics | Status indicators and system diagnostics |
| Power Consumption | Low internal power draw from backplane |
| Operating Temperature | Industrial rated operating range |
| Application Category | Industrial process monitoring and control |
FAQ
Q1: What signal types does the IC220ALG220 support?
A1: The module supports configurable voltage inputs and 4–20 mA current inputs.
Q2: Is the module compatible with VersaMax PLC systems?
A2: Yes, it integrates directly with VersaMax and VersaPoint distributed I/O platforms.
Q3: What resolution does this analog module provide?
A3: It delivers 15-bit resolution for precise industrial measurement applications.
Q4: Can the module operate in harsh industrial environments?
A4: Yes, it is designed for industrial temperature ranges and electrical noise protection.
Q5: Is it suitable for process control applications?
A5: Yes, it supports accurate feedback signals required for PID and closed-loop control systems.
