Overview
Industrial automation systems require stable power distribution when additional I/O modules increase overall energy demand.
The IC200PWB001 booster carrier supports power expansion within the VersaMax PLC architecture developed by GE (General Electric).
This module enables engineers to add supplemental power supplies that extend the electrical capacity of VersaMax control systems.
Therefore, large automation installations maintain consistent voltage levels across multiple baseplates and distributed I/O assemblies.
The IC200PWB001 carrier installs directly into a VersaMax modular rack and integrates seamlessly with adjacent system components.
Moreover, the design simplifies system expansion because technicians mount additional power modules without redesigning the entire PLC cabinet layout.
Many integrators deploy IC200PWB001 in production lines where numerous I/O modules increase backplane energy consumption.
Consequently, the booster carrier maintains stable system performance during continuous industrial operation and heavy load conditions.
Specification
| Parameter | Detailed Specification |
|---|---|
| Manufacturer | GE (General Electric) |
| Product Model | IC200PWB001 |
| Product Type | Power Supply Booster Carrier |
| PLC Platform | VersaMax PLC System |
| Series | VersaMax Modular Automation Platform |
| Primary Function | Carrier module designed to host an auxiliary booster power supply for system power expansion |
| System Role | Provides additional backplane power capacity when system I/O modules exceed standard power supply capability |
| Compatible Power Modules | VersaMax booster power supply modules used with expanded I/O configurations |
| Installation Location | Installed directly on a VersaMax base unit within the PLC rack |
| Backplane Interface | Integrated VersaMax backplane connector for power distribution and module communication |
| Power Distribution Function | Routes additional regulated power from booster supply to the system backplane |
| Electrical Connection Type | Integrated backplane edge connector with modular slot interface |
| Mechanical Mounting | Snaps securely into VersaMax modular baseplate without additional mounting hardware |
| Slot Requirement | Occupies one slot within the VersaMax modular rack |
| Connector Type | Industrial-grade modular edge connector for secure electrical contact |
| Module Housing Material | Industrial thermoplastic enclosure designed for electrical insulation and durability |
| Cooling Method | Passive convection cooling through control cabinet airflow |
| Operating Temperature Range | 0°C to 60°C (32°F to 140°F) typical industrial operating environment |
| Storage Temperature Range | −40°C to 85°C (−40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration Resistance | Designed to meet industrial PLC vibration tolerance standards |
| Shock Resistance | Withstands typical cabinet shock levels in factory automation environments |
| Dimensions (Approx.) | Height: 120 mm / Width: 70 mm / Depth: 45 mm |
| Weight (Approx.) | 0.25 kg (0.55 lb) |
| Module Orientation | Horizontal installation within VersaMax rack assembly |
| Electrical Isolation | Isolation provided through VersaMax backplane power architecture |
| System Expansion Capability | Supports extended VersaMax I/O configurations requiring additional power resources |
| Typical Cabinet Installation | Industrial control panels, automation racks, and PLC control cabinets |
| Maintenance Requirement | Minimal maintenance required; periodic inspection of connectors recommended |
| Typical Service Life | Designed for continuous industrial operation under rated environmental conditions |
FAQ
Q1: Is the IC200PWB001 module new and original?
Yes. The IC200PWB001 module we provide is brand new and original from the factory.
Q2: Do you have IC200PWB001 available in stock?
Yes. We maintain stock availability for IC200PWB001, allowing quick processing of customer orders.
Q3: How quickly can you ship this product?
We usually ship within 3 days to 2 weeks, depending on order quantity and logistics arrangements.
Q4: Which logistics companies do you normally use?
We commonly ship using reliable carriers such as DHL, ensuring fast and secure international delivery.
Q5: Why does a VersaMax system require a booster carrier?
Large VersaMax systems often require additional power because numerous I/O modules increase backplane power consumption.
