Overview
In addition, the IC200MDD842 supports a mix of sinking and sourcing I/O, enabling versatile application across various industrial processes. Its fast response time and high noise immunity ensure accurate signal processing, even in electrically noisy environments. For instance, integrating this module into manufacturing or water treatment systems allows centralized control with minimal wiring complexity. Furthermore, robust LED indicators provide clear module status at a glance, simplifying maintenance and troubleshooting.
Specification
| Parameter | Specification |
|---|---|
| Module Type | Discrete Mixed Input/Output Module |
| Part Number | IC200MDD842 |
| Input Channels | 16 Digital Inputs |
| Output Channels | 16 Digital Outputs |
| Input Type | Sinking or Sourcing |
| Output Type | Sinking or Sourcing, Relay Logic Compatible |
| Input Voltage | 24 V DC nominal |
| Output Voltage | 24 V DC nominal |
| Input Current | 5 mA typical |
| Output Current | 0.5 A per channel maximum |
| Isolation | Optical isolation between channels and field wiring |
| Response Time | <1 ms per channel |
| Power Supply | Supplied via VersaMax backplane |
| Operating Temperature | 0–60°C |
| Storage Temperature | -40–85°C |
| Humidity | 5–95% RH, non-condensing |
| Mounting | VersaMax rack |
| Dimensions (H × W × D) | 120 × 30 × 100 mm |
| Weight | 0.3 kg |
| LED Indicators | Individual channel status, power, and fault |
| Certifications | CE, UL |
| Typical Applications | Manufacturing automation, water/wastewater systems, conveyor control |
FAQ
Q1: Can IC200MDD842 handle both sinking and sourcing I/O simultaneously?
A1: Yes, the module supports mixed discrete input and output types for versatile applications.
Q2: What is the maximum output current per channel?
A2: Each output channel can safely handle up to 0.5 A DC.
Q3: Is this module compatible with all VersaMax PLC racks?
A3: It is compatible with standard VersaMax racks and can be easily added to existing systems.
Q4: How are the channel statuses indicated?
A4: Individual LEDs display input/output status, power, and fault conditions.
