Overview
The IC200BEM103 VersaMax Network Interface Module actively enables robust industrial communications between PLCs and peripheral devices. Moreover, it supports RS-485 serial communication and the widely used Modbus RTU protocol, allowing seamless integration. Therefore, engineers can deploy this module to connect VersaMax PLC systems into distributed automation networks efficiently. Additionally, the compact DIN rail design simplifies panel installation while ensuring industrial-grade reliability.
Furthermore, the IC200BEM103 delivers fast and stable network communication with minimal signal degradation. It also incorporates 120 Ω termination and allows multiple device connections on a single RS-485 bus. As a result, operators gain flexible system expansion while maintaining precise and reliable data transmission.
Specification
| Parameter Category | Specification Detail |
|---|---|
| Manufacturer | GE |
| Product Model | IC200BEM103 |
| Product Type | VersaMax Network Interface Module |
| Communication Interface | RS-485 differential serial communication |
| Protocols Supported | Modbus RTU |
| Maximum Nodes on Network | Up to 32 devices per RS-485 segment |
| Bus Termination | 120 Ω built-in termination resistor |
| Baud Rates Supported | 9600, 19200, 38400, 57600, 115200 bps |
| Mounting | DIN rail standard industrial profile |
| Dimensions | 120 mm × 40 mm × 75 mm (approx.) |
| Weight | 0.3 kg (approx.) |
| Power Supply | 5 VDC from VersaMax backplane |
| Backplane Interface | VersaMax proprietary expansion bus |
| LED Indicators | Network activity, communication error status |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Application Areas | Factory automation, process control, distributed PLC networks |
| Compliance | IEC 61131-2, industrial communication standards |
FAQ
Q1: What communication protocols does IC200BEM103 support?
The IC200BEM103 supports RS-485 serial communication using Modbus RTU protocol.
Q2: How many devices can be connected on a single RS-485 network?
It supports up to 32 nodes per RS-485 segment with proper termination.
Q3: Does it include bus termination?
Yes, the module includes a built-in 120 Ω termination resistor.
Q4: Can it be mounted on standard DIN rails?
Yes, the module is designed for standard industrial DIN rail installation.
Q5: Is this product original and in stock?
Yes, we provide brand-new original factory units with inventory ready for shipment.
