Overview
Configured for master fieldbus communication handling in ABB control system networks, the ABB TC570 (TC570 Master Fieldbus Connection Module) provides direct physical and electrical execution of fieldbus interface functions between controller and network infrastructure.
Suffix Breakdown & Model Matrix
The supplied documentation identifies a single fixed model:
| Parameter | Specification |
|---|---|
| Product Model | TC570 |
| Spare Model | 3BSE001458R1 |
| Product Type | Master Fieldbus Connection Module |
No official suffix decomposition or variant matrix is specified in the provided data.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | TC570 |
| Brand | ABB |
| Spare Model | 3BSE001458R1 |
| Product Type | Master Fieldbus Connection Module |
| Series | ABB Advant OCS / ABB Advant MOD 300 |
| Origin | Sweden |
| Weight | 0.7 kg |
| Dimensions | 5.1 x 15.2 x 17.8 cm (estimated shipping size) |
| Operating Temp | Not specified in supplied documentation |
| Power Consumption | Not specified in supplied documentation |
| Tariff Code | 8537109060 |
| Shipping Location | Webster, NY, USA |
| Application Platform | AC 450 and AC 460 control system environments |
| Communication Function | Master Fieldbus Connection Interface |
Backplane Communication and Firmware Compatibility
Within ABB Advant OCS and Advant MOD 300 architectures, the TC570 functions as a dedicated fieldbus connection module that exchanges communication data through the controller backplane infrastructure. Proper operation depends on firmware compatibility between the installed controller hardware, communication modules, and system software revision.
When replacing an installed module, verification of hardware revision and firmware release alignment is recommended before commissioning. Mismatched revisions may prevent normal communication establishment or network initialization.
Frequently Asked Questions
Q: Does the TC570 support hot replacement while the control system remains energized?
A: The provided documentation does not specify hot-swap capability. Module replacement should follow the applicable ABB maintenance procedure and plant lockout requirements.
Q: Is a firmware compatibility check required after module replacement?
A: Yes. Communication modules operating within controller backplane architectures should be verified for compatibility with the installed controller firmware and system software revision before returning the system to service.
Q: Are operating temperature limits available in the supplied documentation?
A: No. The provided data does not include environmental specifications. Refer to the applicable ABB hardware manual for environmental ratings and installation limits.
Field Installation Guidelines
- Verify module part number and spare number before installation.
- Ensure the module is installed in the designated rack or carrier position defined by the system configuration.
- Maintain proper grounding and shielding practices for all fieldbus communication cabling.
- Route communication cables separately from high-voltage and high-current conductors to minimize electromagnetic interference.
- Inspect backplane connectors and module edge contacts for contamination or mechanical damage before insertion.
- Secure all communication terminations according to plant wiring standards.
- Confirm network communication status and controller diagnostics after installation or replacement activities.
