Overview
In addition, the 07DC92 features a compact and durable structure, enabling seamless integration into complex control networks while ensuring consistent operational stability. Moreover, its efficient design supports fast installation and dependable communication, which ultimately enhances performance and guarantees smooth, continuous industrial operations.
Specification
| Specification | Details |
|---|---|
| Product ID | GJR5252200R0101 |
| ABB Type Designation | 07DC92 |
| EAN | 4013614267642 |
| Catalog Description | 07DC92 Digital In-/Output Module, 24 V DC |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389091 |
| Net Weight | 0.3 kg |
| Operating Temperature | 0 … +55 °C |
| Storage Temperature | -25 … +75 °C |
| Maximum Operating Altitude | 2000 m |
| RoHS Status | No declaration needed |
| Cable Cross-Section | 0.08 … 1.5 mm² |
| Bus Interface | CS31 Slave |
| Fieldbus Interface Type | CS31 Slave |
| Degree of Protection | IP20 |
| I/O Option | Bus module with Onboard IO – 32DC |
| Mounting Options | TH35-15 or TH35-7.5 DIN Rail acc. to IEC 60715 |
| Number of Digital Configurable I/Os | 32 |
| Number of Analog Configurable I/Os | 0 |
| Output Voltage | 24 V DC |
| Output Current | 0.5 A |
| Primary Voltage | 24 V |
| Serial Port | RS-485, CS31 |
| Supply Voltage | 24 V DC |
| Terminal Type | Screw Terminals, Pluggable |
| Product Type | Spare Parts |
| Product Name | 07DC92 Digital In-/Output Module, 24 V DC |
FAQ
Q: Can the 07DC92 module be used in SIL-rated applications?
A: The 07DC92 module is not SIL-rated. For safety-critical applications, consider using modules specifically designed and certified for SIL compliance.
Q: How can I purchase the 07DC92 module?
A: The 07DC92 module can be purchased through authorized ABB distributors or online platforms. Availability may vary by region.
Q: What is the lead time for delivery of the 07DC92 module?
A: Lead times can vary depending on the supplier and region. It’s recommended to contact the supplier directly for estimated delivery times.
Q: Are there any training resources available for the 07DC92 module?
A: ABB offers training resources and documentation for their products. It’s advisable to check ABB’s official website or contact local ABB offices for available training materials.
Manual/Datasheet PDF
07 DC 92 ABB Advant OCS 800xA 32 configurable I O 24 V DC datasheet
