Overview
The ABB XVC767AE105 3BHB007209R0105 is identified in the supplied information as an industrial control module. However, the exact board function and its electrical interface have not been independently confirmed. The supplied specifications include a 0-50 A current range, an accuracy of +/-0.5% of full scale, and a response time of 5 ms. These values require verification against documentation for the exact part number before they are used for system design or replacement selection.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | XVC767AE105 |
| Order Number | 3BHB007209R0105 |
| Brand | ABB |
| Product Type | Industrial Control Circuit Board |
| Weight | 0.2 kg |
| Dimensions | 65 mm x 65 mm x 20 mm |
| Current Range | 0-50 A (unverified) |
| Accuracy | +/-0.5% of full scale (unverified) |
| Response Time | 5 ms (unverified) |
Configuration and Verification
The complete model designation is important when identifying this board for maintenance or replacement. Confirm both XVC767AE105 and 3BHB007209R0105 against the installed component label and equipment documentation before ordering.
The supplied information also lists a nominal 24 VDC supply and operating temperatures of -20 to +60 deg C, with an alternative range of -40 to +85 deg C. These values have not been confirmed for this exact board. The IP67 and IP54 protection ratings are also inconsistent and should not be used as verified enclosure specifications.
Frequently Asked Questions
Q: Are XVC767AE105 and 3BHB007209R0105 the same product?
A: The supplied information associates these two designations with the same ABB component. Verify both identifiers against the original nameplate before purchasing a replacement.
Q: Can the 0-50 A current range and +/-0.5% accuracy be used for engineering calculations?
A: Not yet. These values require confirmation from a technical document applicable to the exact model. Do not use them to establish measurement limits, protection settings, or calibration requirements without verification.
Q: Is this board compatible with other ABB XVC series modules?
A: Compatibility has not been established. Similar model prefixes do not guarantee matching electrical characteristics, connectors, or system functions. Check the equipment configuration and approved replacement documentation before installation.
