Overview
In addition, the module integrates smoothly with ABB protection relays, enabling flexible configuration and dependable trip isolation. Therefore, engineers can confidently use it to enhance system reliability and minimize operational downtime.
Specification
| Parameter | Specification |
|---|---|
| Product Model | 1MRK002133-ABr03 |
| Product Type | PC Board Relay Card |
| Function | Trip relay interface / auxiliary relay routing |
| Relay Outputs | Multiple isolated relay channels |
| Contact Type | Form A / dry contact (depending on relay configuration) |
| Coil Voltage | 24 V DC or 48 V DC (model dependent) |
| Contact Rating | 5–8 A @ 250 V AC / 30 V DC typical |
| Isolation Strength | ≥ 2 kV between coil and contacts |
| Response Time | < 10 ms |
| PCB Construction | Industrial-grade multilayer PCB |
| Connector Type | Board-mounted terminal connectors |
| Operating Temperature | –20°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Humidity | 5–95% RH non-condensing |
| Mounting Format | Plug-in card for ABB protection systems |
| Application Compatibility | ABB protection relays in the Relion and legacy series |
| Certifications | CE, IEC standards for protective relay hardware |
FAQ
It works with ABB protection and control systems that accept plug-in relay interface cards.
Q2: Does the relay card provide electrical isolation?
Yes. It offers isolation between relay coils, contacts, and control circuits.
Q3: Is the module suitable for harsh substation conditions?
Yes. Its PCB and relay components meet utility-grade temperature and humidity requirements.
Q4: How often should the card be serviced?
Most installations operate for years without service, though periodic connector checks are recommended.
