PM583-ETH 1SAP140300R0271 ABB Advant AC500 Processor module

Overview

Configured for Ethernet-based controller communication, program execution, and process data handling in ABB AC500 systems, the ABB PM583-ETH (PM583 Processor Module) provides direct electrical execution. The processor integrates CPU resources, Ethernet connectivity, serial communication interfaces, and local operating functions for control-level data exchange within the AC500 automation architecture.

Suffix Breakdown & Model Matrix

The designation PM583-ETH is documented as a fixed ABB catalog model associated with product number 1SAP140300R0271. The available documentation does not define a suffix matrix or configurable ordering structure for this processor variant.

Hardware Specifications

I/O Density Scaling and System Expansion

The PM583-ETH processor acts as the central control unit of the AC500 platform and manages process data exchange between application programs and connected I/O modules. As the system expands, the processor coordinates communication tasks, memory resources, and I/O transactions across the controller architecture.

Additionally, the integrated Ethernet interface enables engineering access, controller-to-controller communication, and process data transfer. As users add local or distributed I/O modules, the processor handles larger data volumes and increased communication traffic. Therefore, engineers should evaluate memory utilization, scan performance, and network loading during system design.

Furthermore, firmware versions directly influence interoperability between the processor, engineering software, and expansion hardware. Before commissioning or upgrading a system, engineers should verify compatibility across all installed AC500 components to maintain consistent operation.

Frequently Asked Questions

Q: Does the PM583-ETH include integrated Ethernet communication?
A: Yes. The processor includes a built-in Ethernet interface and two RS232/485 serial communication ports, allowing network communication and serial device integration from the controller.

Q: Can firmware revisions affect system compatibility?
A: Yes. Different firmware revisions can influence communication behavior, hardware recognition, and engineering software support. Therefore, engineers should confirm version compatibility before performing firmware updates or downloading applications.

Q: Is hot-swapping supported for processor replacement?
A: The available documentation does not define a hot-swap procedure for the PM583-ETH. Consequently, technicians should remove system power before replacing the processor and should follow ABB maintenance procedures during installation.

Field Installation Guidelines

• First, mount the processor module onto the designated AC500 DIN rail and confirm proper mechanical engagement.
• Next, verify that the power supply provides a voltage within the specified 20.4 to 28.8 VDC operating range before energizing the controller.
• Additionally, route Ethernet and serial communication cables separately from high-current power conductors, motor feeders, and drive output wiring to minimize electromagnetic interference.
• During cable installation, connect shields according to plant grounding practices and maintain a continuous protective earth path.
• Before startup, inspect all expansion modules and backplane connections to confirm secure electrical and mechanical connections.
• Furthermore, maintain enclosure conditions within the specified operating temperature limits throughout system operation.
• Finally, validate network parameters, controller addressing, firmware compatibility, and communication settings before commissioning the automation system.
