Overview
IS220PAICH1A functions as an analog input pack within the GE Mark VIe control platform.
GE designs this module for turbine and industrial process control applications.
The pack connects directly to compatible terminal boards in the Mark VIe system.
Therefore, it enables high-accuracy acquisition of critical process signals.
IS220PAICH1A integrates signal conditioning, A/D conversion, and Ethernet communication in one compact housing.
Consequently, engineers reduce cabinet wiring and improve diagnostic visibility.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Series | Mark VIe |
| Model | IS220PAICH1A |
| Product Type | Analog Input I/O Pack |
| System Platform | GE Mark VIe Control System |
| Input Channel Type | Analog current inputs |
| Supported Signal Range | 4–20 mA nominal |
| Input Impedance | 250 Ω typical for current loop measurement |
| A/D Conversion Resolution | 16-bit per channel |
| Conversion Accuracy | ±0.1% of full scale typical |
| Input Isolation | Channel-to-system isolation through terminal board |
| Internal Processor | Embedded local microprocessor for signal processing |
| Power Supply Voltage | 24 V DC nominal (18–32 V DC range) |
| Power Consumption | 8–10 W typical under full load |
| Ethernet Communication | 2 × RJ45 ports, 10/100Base-T |
| Network Redundancy | Dual Ethernet support for controller redundancy |
| Communication Protocol | Ethernet-based I/O protocol for Mark VIe |
| Diagnostic Features | Power, Link, Activity, and Status LED indicators |
| Onboard Diagnostics | Continuous self-test and channel health monitoring |
| Data Update Rate | Deterministic real-time data exchange with controller |
| Mounting Method | Direct mounting to compatible terminal board |
| Housing Material | Industrial-grade metal enclosure |
| Length | Approx. 200 mm |
| Width | Approx. 100 mm |
| Height | Approx. 60 mm |
| Weight | Approx. 0.9 kg |
| Operating Temperature | –30°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Relative Humidity | 5%–95% non-condensing |
| Vibration Resistance | Suitable for turbine and heavy industrial environments |
| Compliance | Designed to meet GE industrial control standards |
FAQ
Q1: Is IS220PAICH1A brand new and original?
Yes, we supply 100% brand new original GE products.
Q2: Do you have IS220PAICH1A in stock?
Yes, we keep stock available for immediate delivery.
Q3: How quickly can you ship after payment?
We ship within 3 days to 2 weeks depending on order size.
Q4: Which logistics companies do you usually use?
We commonly use DHL and other international express carriers.
Q5: What if the module shows quality problems?
We support returns within 30 days if quality issues occur.
Q6: Does IS220PAICH1A support redundant Ethernet connections?
Yes, it provides dual Ethernet ports for network redundancy.
