Overview
The IS200EDCFG1AED board measures and monitors DC feedback signals for GE Mark VIe exciter systems.
Engineers install IS200EDCFG1AED to provide precise field current monitoring and ensure stable generator output.
Additionally, the board integrates directly with Mark VIe I/O packs and controller modules.
Therefore, plants rely on IS200EDCFG1AED to maintain accurate excitation feedback and optimize turbine performance.
The module incorporates high-reliability resistors, capacitors, and signal conditioning circuits.
Consequently, IS200EDCFG1AED delivers stable voltage readings under fluctuating load conditions.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | IS200EDCFG1AED |
| Product Type | Direct Current Feedback Board |
| Series | Mark VIe Speedtronic Control System |
| Function | Measures and transmits DC feedback signals from generator field windings |
| Input Voltage | 24 VDC nominal |
| Input Voltage Range | 20 – 28 VDC |
| Output Signals | Conditioned DC feedback voltage to Mark VIe controllers |
| Accuracy | ±0.5% typical for feedback measurement |
| Protection Features | Overcurrent protection, thermal protection, voltage spike protection |
| Status Indicators | Multi-color LEDs for operational and fault status |
| PCB Construction | Multilayer double-sided board with surface-mount high-reliability components |
| Capacitors | Local energy storage to stabilize signal readings |
| Fuses | Onboard fast-blow fuses for protection of sensitive circuits |
| Mounting | Panel or UCPA I/O pack installation |
| Cooling | Passive cooling via cabinet airflow |
| Approximate Dimensions | 140 mm × 90 mm × 50 mm |
| Approximate Weight | 0.3 – 0.4 kg |
| Environmental Rating | Industrial turbine control cabinet conditions |
| Communication Interface | DC feedback lines to Mark VIe controllers |
| Application | Gas turbines, steam turbines, hydro turbines, generator excitation monitoring |
FAQ
Q1: Is the IS200EDCFG1AED board new and original?
Yes. We provide IS200EDCFG1AED as brand-new original factory hardware with sealed packaging.
Q2: Do you keep IS200EDCFG1AED in stock?
Yes. Our warehouse stocks IS200EDCFG1AED for immediate order fulfillment.
Q3: How quickly can you ship the IS200EDCFG1AED module?
Orders usually ship within 3 days to 2 weeks, depending on total order size.
Q4: What voltage input does IS200EDCFG1AED support?
The IS200EDCFG1AED operates on nominal 24 VDC, with a safe range of 20–28 VDC.
Q5: Which turbines can use IS200EDCFG1AED?
It is compatible with GE Mark VIe gas, steam, and hydro turbine excitation systems.
Q6: Which logistics services do you use?
We commonly ship IS200EDCFG1AED via DHL and other international express providers.
