Overview
It accurately captures on and off states, therefore supporting precise monitoring of equipment status and process conditions.
Moreover, the module integrates smoothly into Bailey distributed control architectures without disrupting existing control strategies.
Engineers commonly select the IMDSI22 where stable digital signal handling directly influences safety and operational continuity.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB (Bailey Controls) |
| Product Model | IMDSI22 |
| Product Type | Digital Input Module |
| Compatible Systems | ABB Bailey Infi 90 and Net 90 DCS |
| Number of Input Channels | 32 digital input channels |
| Input Signal Type | Discrete voltage or contact-based inputs |
| Nominal Input Voltage | 24 VDC industrial digital signals |
| Input Threshold Levels | Defined logic high and logic low detection |
| Channel Isolation | Electrical isolation between field inputs and system electronics |
| Input Filtering | Noise suppression for stable signal recognition |
| Scan Update Rate | Deterministic update synchronized with system scan cycle |
| Backplane Interface | Infi 90 / Net 90 system backplane |
| Power Supply Requirement | +5 VDC supplied from backplane |
| Typical Current Consumption | Approximately 500 mA |
| Maximum Current Consumption | Up to 800 mA |
| Diagnostic Features | Channel status indicators and module self-diagnostics |
| Operating Temperature Range | 0 °C to +70 °C (32 °F to 158 °F) |
| Storage Temperature Range | −40 °C to +85 °C (−40 °F to 185 °F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Installation Location | Standard Infi 90 / Net 90 module rack |
| Approximate Module Weight | 1.0 kg (2.2 lbs) |
| Industrial Suitability | Designed for continuous-duty control environments |
FAQ
A1: The IMDSI22 collects discrete digital signals from field devices and delivers their status to the control system.
Q2: How many digital input channels does the IMDSI22 support?
A1: It supports thirty-two independent digital input channels within a single module.
Q3: Which systems are compatible with the IMDSI22?
A1: The module is designed specifically for ABB Bailey Infi 90 and Net 90 distributed control systems.
Q4: Does the IMDSI22 provide electrical isolation?
A1: Yes, moreover it isolates field inputs from system electronics to improve noise immunity and reliability.
Q5: Can the IMDSI22 be used for safety interlock monitoring?
A1: It supports reliable status monitoring, although overall safety compliance depends on complete system design.
Q6: Is the IMDSI22 suitable for long-running legacy installations?
A1: Yes, engineers frequently use it to maintain stable operation in mature Infi 90 and Net 90 systems.
