Overview
The ABB IMDSO14 Digital Slave Output Module is a critical element within the Bailey INFI-90 and Net 90 distributed control systems. It provides 16 discrete output channels, each designed to handle industrial-level switching and automation tasks. With its compact size and reliable backplane connectivity, the IMDSO14 ensures stable performance and seamless communication with other system modules.
This module suits applications requiring precise digital control, such as driving relays, solenoids, or indicators. The IMDSO14 stands out because it offers consistent response times, real-time diagnostic LEDs, and strong integration with existing ABB Bailey infrastructures.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IMDSO14 |
| Manufacturer | ABB / Bailey Controls |
| Product Category | Digital Slave Output Module (INFI-90 / Net 90 Series) |
| Number of Output Channels | 16 channels |
| Output Type | Discrete digital outputs |
| Voltage Rating | 24 V DC nominal |
| Output Current Capacity | 0.5 A per channel (typical) |
| Communication Interface | System backplane connection |
| Indicators | Front-panel LEDs for channel and module status |
| Diagnostics | Built-in fault detection and status monitoring |
| Power Requirements | Supplied via INFI-90 backplane |
| Module Dimensions | Approx. 381 mm × 30 mm × 244 mm (15 in × 1.2 in × 9.6 in) |
| Module Weight | ~1.3 kg (2.9 lb) |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | –40°C to +85°C |
| Relative Humidity | 5%–95% non-condensing |
