Overview
It captures on and off status information accurately, therefore enabling precise monitoring of equipment and process conditions.
Moreover, the module integrates seamlessly into Bailey DCS architectures, supporting deterministic control and stable plant operation.
Engineers trust the IMDSI12 in environments where digital signal integrity directly affects safety, sequencing, and interlocking performance.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB (Bailey Controls) |
| Product Model | IMDSI12 |
| Product Type | Digital Input Module |
| Compatible Systems | ABB Bailey Infi 90 and Net 90 DCS |
| Number of Input Channels | 16 digital input channels |
| Input Signal Type | Discrete contact or voltage-based digital signals |
| Nominal Input Voltage | 24 VDC (typical industrial control signals) |
| Input State Detection | Logic high and logic low with defined thresholds |
| Input Isolation | Electrical isolation between field inputs and system logic |
| Scan Update Rate | Deterministic scan synchronized with system cycle |
| Backplane Interface | Infi 90 / Net 90 system backplane |
| Power Supply Requirement | +5 VDC supplied from system backplane |
| Typical Current Consumption | Approximately 450 mA |
| Maximum Current Consumption | Up to 700 mA |
| Diagnostic Features | Channel status monitoring and module self-diagnostics |
| Operating Temperature Range | 0 °C to +70 °C (32 °F to 158 °F) |
| Storage Temperature Range | −40 °C to +85 °C (−40 °F to 185 °F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Installation Location | Standard Infi 90 / Net 90 module rack |
| Approximate Module Weight | 0.9 kg (2.0 lbs) |
| Industrial Suitability | Designed for continuous-duty control environments |
FAQ
A1: The IMDSI12 collects discrete on and off signals from field devices and transmits their status to the control system.
Q2: How many digital inputs does the IMDSI12 support?
A1: It supports sixteen independent digital input channels within a single module.
Q3: Which systems are compatible with the IMDSI12?
A1: The module is designed specifically for ABB Bailey Infi 90 and Net 90 distributed control systems.
Q4: Does the IMDSI12 provide electrical isolation?
A1: Yes, moreover it isolates field inputs from system logic to improve noise immunity and system protection.
Q5: Can the IMDSI12 be used in safety-related applications?
A1: It supports reliable status monitoring, although overall safety compliance depends on complete system design.
Q6: Is the IMDSI12 suitable for long-running legacy installations?
A1: Yes, engineers frequently use it to maintain stable operation in mature Infi 90 and Net 90 systems.
