Overview
It manages data exchange between control processors and system nodes, therefore ensuring timely and coordinated process execution.
Moreover, the module acts as a critical backbone component, supporting real-time control traffic across the plant network.
Engineers rely on the INNPM01 to maintain predictable system behavior in large-scale, distributed automation architectures.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB (Bailey Controls) |
| Product Model | INNPM01 |
| Product Type | Network Processing Module |
| Compatible Systems | ABB Bailey Infi 90 and Net 90 DCS |
| Primary Function | Network message processing and data routing |
| Network Architecture | Infi-Net distributed control network |
| Processor Type | Dedicated network communication processor |
| Data Handling | Deterministic, real-time message scheduling |
| Communication Role | Master network node for system data exchange |
| Backplane Interface | Infi 90 / Net 90 system backplane |
| Power Supply Requirement | +5 VDC supplied by system backplane |
| Typical Power Consumption | Approximately 600 mA |
| Maximum Power Consumption | Up to 800 mA |
| Diagnostic Features | Built-in self-test and network status reporting |
| Operating Temperature Range | 0 °C to +70 °C (32 °F to 158 °F) |
| Storage Temperature Range | −40 °C to +85 °C (−40 °F to 185 °F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Installation Location | Standard Infi 90 / Net 90 module rack |
| Approximate Module Weight | 1.0 kg (2.2 lbs) |
| Industrial Compliance | Designed for continuous industrial operation |
FAQ
A1: The INNPM01 manages real-time network communication and message routing within ABB Bailey Infi 90 and Net 90 systems.
Q2: How does the INNPM01 improve overall system performance?
A1: By offloading network processing tasks, it reduces controller workload and therefore improves system responsiveness and stability.
Q3: Which control systems are compatible with the INNPM01?
A1: The module is designed specifically for ABB Bailey Infi 90 and Net 90 distributed control system architectures.
Q4: Is the INNPM01 suitable for large or complex control networks?
A1: Yes, moreover it supports deterministic communication, making it ideal for large-scale distributed automation systems.
Q5: Does the INNPM01 execute control logic or process calculations?
A1: No, it focuses on network data handling, while control processors execute logic and process algorithms.
Q6: Can the INNPM01 be used in long-running legacy installations?
A1: Certainly, engineers often select it to maintain reliable communication in mature Infi 90 and Net 90 systems.
