Overview
In addition, the module features advanced protection mechanisms, including overload and short-circuit safeguards, which enhance system reliability. Technicians also benefit from clear status indicators, simplifying monitoring and maintenance. Furthermore, its rugged construction ensures long-term durability in industrial environments.
Specification
| Parameter | Specification |
|---|---|
| Module Type | Power Supply Module |
| Series | GE Series 90-70 |
| Model | IC697PWR724 |
| Input Voltage | 120/240 VAC, 50/60 Hz |
| Input Voltage Range | 100–250 VAC |
| Input Current | 2.0 A @ 120 VAC, 1.0 A @ 240 VAC |
| Frequency | 50/60 Hz |
| Output Voltage | 5 VDC and 24 VDC |
| Output Current | 5 VDC: 4.5 A, 24 VDC: 4.0 A |
| Power Rating | 130 W total |
| Efficiency | >85% typical |
| Hold-up Time | 20 ms minimum at full load |
| Voltage Regulation | ±2% steady state |
| Load Regulation | ±1% for 0–100% load change |
| Ripple & Noise | <50 mV peak-to-peak |
| Protections | Overload, short-circuit, thermal shutdown |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5–95%, non-condensing |
| Altitude | Up to 2000 m (6,562 ft) |
| MTBF | >50,000 hours at 25°C |
| Mounting | Rack-mount, rear-mount compatible with Series 90-70 |
| Dimensions (H × W × D) | 2.5 × 12.0 × 12.0 in (63.5 × 305 × 305 mm) |
| Weight | 3.0 kg |
| Certifications | UL, CE, CSA compliant |
| Indicators | LED status indicators for power and faults |
| Cooling | Convection or forced airflow in rack |
| Connection | Standard 90-70 backplane connectors |
FAQ
A1: The module supports 120/240 VAC at 50/60 Hz for flexible industrial installations.
Q2: Can the IC697PWR724 handle multiple Series 90-70 modules simultaneously?
A2: Yes, it provides sufficient DC power to support multiple CPUs, I/O, and communication modules.
Q3: Does it include protective features?
A3: Yes, the module incorporates overload, short-circuit, and thermal protection mechanisms.
Q4: How can technicians monitor the module status?
A4: Clear LED indicators provide real-time power and fault status information.
Q5: Is the module suitable for harsh industrial environments?
A5: Yes, its rugged construction ensures reliable long-term operation in demanding conditions.
