Overview
It provides precision analog input and output channels for monitoring and controlling industrial processes.
Moreover, the compact module design simplifies panel layout while integrating seamlessly with existing micro PLC systems.
In addition, its high-resolution measurements ensure accurate data acquisition and control for critical applications.
Engineers choose this unit to add analog functionality without replacing the core controller.
Therefore, system integrators can expand automation systems efficiently while maintaining consistent performance.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC200UEX624 |
| Series | VersaMax Micro PLC |
| Module Type | Analog Expansion Unit |
| Analog Inputs | 8 differential or 16 single-ended channels |
| Input Range | ±10 VDC, 0–10 VDC, 0–20 mA, or 4–20 mA configurable |
| Input Resolution | 12-bit A/D conversion |
| Analog Outputs | 4 channels |
| Output Range | 0–10 VDC or 0–20 mA, configurable |
| Output Resolution | 12-bit D/A conversion |
| Accuracy | ±0.2% of full scale typical |
| Input Impedance | >100 kΩ for voltage inputs |
| Output Load | 500 Ω max for current outputs |
| Sampling Rate | Up to 500 samples/sec per channel |
| Status Indicators | Power, module OK, and communication LEDs |
| Communication | VersaMax backplane interface to CPU |
| Mounting | DIN rail or backplane slot |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5–95% non-condensing |
| Vibration Resistance | Industrial panel compatible |
| EMC Compliance | Meets industrial electromagnetic compatibility standards |
| Safety Certifications | Industrial control equipment compliance |
| Dimensions | Compact form factor for high-density panels |
| Weight | Lightweight module design |
FAQ
Q1: What type of module is the IC200UEX624?
A1: It is an analog expansion unit for the GE VersaMax Micro PLC platform.
Q2: How many analog input channels does it provide?
A2: The module provides 8 differential or 16 single-ended analog input channels.
Q3: What analog output channels are available?
A3: It offers 4 configurable analog output channels for voltage or current signals.
Q4: Can it measure temperature, pressure, or flow sensors directly?
A4: Yes, the module supports 0–10 V, ±10 V, 0–20 mA, and 4–20 mA signals.
Q5: How does the module communicate with the CPU?
A5: It connects via the VersaMax backplane interface for seamless integration with micro PLCs.
