Overview
It supports up to 40 digital I/O points, providing stable operation for compact automation systems.
Moreover, its integrated design reduces cabinet space and simplifies system wiring requirements.
In addition, the module ensures consistent performance across various industrial applications.
Engineers select this power supply for dependable startup and continuous operation in small to medium-sized machines.
Therefore, system integrators can implement flexible control solutions without additional external power components.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC200UDR140 |
| Series | VersaMax Micro PLC |
| Module Type | 40-Point Power Supply Module |
| Input Voltage | 120/240 VAC, single-phase, auto-ranging |
| Input Frequency | 50–60 Hz |
| Output Voltage | 5 VDC logic power for backplane and micro PLC modules |
| Maximum Output Current | Up to 4 A (system dependent) |
| Number of Supported I/O Points | 40 digital points |
| Status Indicators | Power OK LED, Output Status LED |
| Protection | Overload, short circuit, and thermal protection |
| Mounting | DIN rail or VersaMax backplane |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5–95% non-condensing |
| Vibration Resistance | Industrial environment compatible |
| EMC Compliance | Meets industrial electromagnetic compatibility standards |
| Safety Certifications | Meets industrial control equipment safety standards |
| Dimensions | Compact modular design for efficient panel installation |
| Weight | Lightweight for versatile integration |
FAQ
Q1: What type of module is the IC200UDR140?
A1: It is a 40-point power supply module for the GE VersaMax Micro PLC platform.
Q2: What input voltage does this module accept?
A2: The module supports 120/240 VAC, single-phase, auto-ranging input.
Q3: How many I/O points can this module support?
A3: It supports up to 40 digital I/O points within the VersaMax Micro system.
Q4: Does the module include protection features?
A4: Yes, it has overload, short circuit, and thermal protection to safeguard connected devices.
Q5: How does the module indicate operating status?
A5: Front-panel LEDs display power presence and output status for quick diagnostics.
Q6: Is it suitable for compact industrial panels?
A6: Yes, the module’s compact form factor fits high-density panels for small to medium automation systems.
