Overview
It integrates CPU processing, communication ports, and flexible I/O in a single modular unit.
Moreover, the controller’s small footprint allows engineers to design dense control panels efficiently.
In addition, its reliable processing ensures deterministic control for repetitive industrial tasks.
Engineers often choose this controller to reduce wiring complexity and accelerate machine commissioning.
Therefore, system integrators can implement versatile automation solutions without additional interface modules.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC200UDD120 |
| Series | VersaMax Micro PLC |
| Controller Type | Compact PLC with integrated digital I/O |
| Processor | Embedded industrial-grade microprocessor |
| Program Execution | Deterministic cyclic scan with predictable timing |
| User Memory | Approx. 16 KB logic program memory |
| Data Memory | Internal data registers and variables |
| Digital Inputs | 16 points, 24 VDC typical |
| Digital Outputs | 12 points, relay or transistor output depending on model |
| Input Voltage Range | 0–30 VDC typical industrial range |
| Output Voltage | Relay outputs: up to 250 VAC / 30 VDC |
| Output Current Rating | 2 A per point (resistive load typical) |
| Power Supply Requirement | 24 VDC nominal |
| Communication Port | Serial port (RS-232/RS-485) |
| Supported Protocols | Standard industrial serial communication protocols |
| Mounting | DIN rail or panel mounting |
| Status Indicators | Power, Run, Fault, I/O activity LEDs |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5–95% non-condensing |
| Vibration Resistance | Suitable for industrial environments |
| EMC Compliance | Designed to meet industrial EMC standards |
| Safety Certification | Meets industrial control safety standards |
| Dimensions | Compact module for small panel installation |
| Weight | Lightweight for modular control racks |
FAQ
Q1: What type of PLC is the IC200UDD120?
A1: It is a compact micro PLC within the GE VersaMax Micro series.
Q2: Does it include integrated I/O?
A2: Yes, it provides 16 digital inputs and 12 digital outputs for direct device connections.
Q3: What power supply is required for this controller?
A3: It operates on a 24 VDC nominal industrial power supply.
Q4: Can the IC200UDD120 expand with additional I/O modules?
A4: Yes, it supports distributed VersaMax I/O modules for scalable automation.
Q5: How does the controller indicate system status?
A5: LEDs display power, run state, fault conditions, and I/O activity.
Q6: Is this controller suitable for small machine automation?
A6: Yes, it is designed for packaging machinery, conveyors, and compact process control systems.
