Overview
Specification
| Parameter | Specification |
|---|---|
| Module Type | Expansion Transmitter Module |
| Part Number | IC200ETM001 |
| Input Channels | 8 Analog Inputs |
| Supported Signal Types | 4–20 mA, 0–10 V |
| Input Resolution | 12-bit |
| Input Impedance | Voltage: >100 kΩ, Current: 250 Ω |
| Accuracy | ±0.25% of Full Scale |
| Isolation | 500 V AC between input channels and field wiring |
| Response Time | < 5 ms per channel |
| Power Supply | 5 V DC from base unit |
| Communication Interface | VersaMax backplane |
| Operating Temperature | 0–60°C |
| Storage Temperature | -40–85°C |
| Humidity | 5–95% RH, non-condensing |
| Mounting | DIN rail or VersaMax rack |
| Dimensions (H × W × D) | 120 × 30 × 100 mm |
| Weight | 0.25 kg |
| LED Indicators | Power and module status |
| Certifications | CE, UL |
| Safety & Protection | Overvoltage protection on all inputs |
| Typical Applications | Process monitoring, energy management, remote sensor signal expansion |
FAQ
Q1: Can IC200ETM001 handle both current and voltage signals simultaneously?
A1: Yes, the module supports mixed 4–20 mA and 0–10 V inputs across its channels.
Q2: Is the module hot-swappable?
A2: No, it must be powered down before installation or removal to ensure safety.
Q3: How many channels can one PLC handle with this module?
A3: Each IC200ETM001 provides 8 inputs, and multiple modules can be added depending on the rack capacity.
Q4: What is the maximum operating temperature?
A4: The module operates reliably up to 60°C ambient temperature.
