Overview
The Honeywell 51202329-601, also cataloged as the 51202329 I/O Link Cable, provides physical connectivity between Series C I/O components within Honeywell Experion PKS control architectures. Its three-drop configuration supports distributed I/O link connections with a 6-inch (152 mm) drop pitch.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 51202329-601 |
| Base Model | 51202329 |
| Brand | Honeywell |
| Product Type | I/O Link Cable / Drop Cable |
| System Compatibility | Honeywell Series C |
| Application | Experion PKS C300 / Series C I/O Architecture |
| Number of Drops | 3 |
| Drop Pitch | 6 inches (152 mm) |
| Identification Color | Yellow |
| Jacket Color | Gray / Violet variants |
| Weight | Approximately 0.082-0.1 kg |
Series C I/O Link Connectivity and Signal Integrity
The 51202329-601 provides a physical connection path for Series C I/O communication. Its three-drop arrangement accommodates multiple connection points within the I/O architecture.
Furthermore, the 6-inch (152 mm) drop pitch defines the spacing between cable drops. This spacing determines the physical alignment of the cable assembly with the corresponding I/O connection points.
The yellow identification label distinguishes the cable assembly in configurations where cable identification is required. However, the supplied specifications do not establish a universal color-coding rule for redundant configurations.
The cable supports communication connectivity rather than independent signal conditioning or analog measurement. Therefore, its electrical performance depends on the connected system hardware and the applicable Honeywell installation requirements.
Frequently Asked Questions (FAQ)
Q: How many connection drops does the Honeywell 51202329-601 provide?
A: The cable assembly provides three drops with a nominal spacing of 6 inches (152 mm).
Q: Is the 51202329-601 compatible with Honeywell Series C systems?
A: The specified application is Honeywell Series C I/O architecture, including Experion PKS C300-related configurations. Verify the exact connection arrangement against the system configuration documentation.
Q: Does the 51202329-601 require an independent power supply?
A: No independent power consumption is specified. The component functions as a passive I/O link cable assembly rather than a powered electronic module.
Field Installation Guidelines
- Verify the complete part number, 51202329-601, against the system bill of materials before installation.
- Confirm the three-drop arrangement and 6-inch (152 mm) pitch match the intended I/O connection positions.
- Inspect the cable jacket, connectors, and identification label for physical damage before installation.
- Route the cable according to the applicable Honeywell Series C installation documentation.
- Maintain separation from high-voltage power conductors where required by site wiring practices.
- Avoid excessive bending, tensile loading, and mechanical stress at the cable termination points.
- Confirm connector alignment and secure mechanical engagement before energizing the associated system.
- Verify communication status through the applicable controller and I/O diagnostics after installation.
