Overview
Specification
| Parameter | Description |
|---|---|
| Manufacturer | HIMA |
| Model / Part No. | B9302 / B 9302 |
| Module Type | I/O Slot Rack / Assembly Kit |
| Rack Size | 4 units high, 19″ mounting (K1406 frame) |
| Number of I/O Slots | 16 slots for I/O modules (slots 1–16) |
| Coupling / Bus Module | 1 × F7553 in slot 17 |
| Power Distribution (optional) | Up to 4 × F7133 modules in slots 18–21 |
| Flat Cable (BV7032) | Standard lengths: 0.5 m (B9302-0.5) or 1.0 m (B9302-1) |
| Max Bus Length | Up to 30 m (depending on design) |
| Rear Connections | Fuse monitoring, supply lines, I/O bus connectors |
| Dimensions | Approx. 205 mm depth × 176 mm height × 60 mm cable tray |
| Earth / Grounding | Earth bar with Faston 6.3 × 0.8 mm connection per slot |
FAQ
A1: Yes, all products are 100% brand new and factory original.Q2: Do you have B9302 in stock?
A2: Yes, we maintain stock and ship orders within 3 days to 2 weeks, depending on order volume.
Q3: What shipping methods are available?
A3: We use DHL, FedEx, UPS, and other reliable global carriers.
Q4: What if there is a quality issue after delivery?
A4: We offer a 30-day return policy for verified quality issues.
Q5: Can I order custom cable lengths?
A5: Yes, B9302 supports customized BV7032 cable lengths as required.
Q6: What is the maximum bus length supported?
A6: The rack supports up to 30 m of total bus length with proper installation.
