Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CI868K01-eA |
| Brand | ABB |
| Origin | Sweden |
| Product Type | IEC 61850 Interface Communication Module |
| Product ID | 3BSE048845R2 / 3BSE048845R1 |
| System Compatibility | ABB System 800xA, AC 800M |
| Communication Protocol | IEC 61850 Edition 1 |
| Supported Services | MMS client/server communication and GOOSE event messaging |
| Mounting Type | AC 800M module rack / DIN-rail mounting |
| Weight | Approx. 0.535 kg to 0.7 kg |
| Dimensions | 59 mm W x 186 mm H x 127.5 mm D |
| Environmental Category | WEEE Category 5 Small Equipment |
ABB Industrial Control Network Integration
The CI868K01-eA uses ABB AC 800M controller backplane communication for IEC 61850 network integration. The module transfers electrical automation data through standardized communication services, including MMS for supervisory data exchange and GOOSE for event-driven protection signals.
Furthermore, the module supports ABB System 800xA engineering environments where controller-level communication requires IEC 61850 connectivity. The hardware design follows ABB industrial control architecture principles, including backplane bus communication velocity optimization, I/O network expansion capability, and firmware flash compatibility within supported controller configurations.
The module operates as an interface component between AC 800M controllers and IEC 61850 compliant intelligent electronic devices (IEDs). Therefore, configuration requires correct network addressing, protocol parameter assignment, and controller application integration.
Frequently Asked Questions
Q: What communication protocols does the ABB CI868K01-eA support?
A: The CI868K01-eA supports IEC 61850 Edition 1 communication, including MMS client/server data exchange and GOOSE messaging for high-speed event communication.
Q: Can the CI868K01-eA operate independently without an AC 800M controller system?
A: No. The module is designed as an AC 800M system communication component and requires integration with the ABB System 800xA control environment.
Q: What installation considerations apply to this communication module?
A: Installation requires correct rack mounting, approved backplane connection, proper network cable routing, and electromagnetic compatibility practices for industrial environments.
Field Installation Guidelines
- Install the CI868K01-eA in the designated AC 800M controller rack position according to ABB hardware configuration requirements.
- Verify that the module connector and backplane interface are correctly seated before applying system power.
- Separate IEC 61850 communication cables from high-voltage power conductors to reduce electromagnetic interference.
- Connect cable shields according to plant grounding standards and maintain proper EMC practices.
- Confirm controller firmware compatibility and System 800xA configuration parameters before commissioning.
- Check network addressing, IEC 61850 device mapping, and communication diagnostics after installation.
