Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model / Part Number | CI810V2 / 3BSE013224R1 |
| Module Type | AF100 Field Communication Interface |
| Communication Protocol | AF100 fieldbus |
| System Compatibility | ABB S800 I/O, 800xA, Advant OCS |
| Function | Connects multiple AF100 field devices to controller networks |
| Mounting Type | DIN-rail or panel mount |
| Power Supply | Powered via S800 I/O backplane |
| Operating Temperature | −20°C to +60°C |
| Storage Temperature | −40°C to +85°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Dimensions (W×H×D) | ~142 mm × 53 mm × 65 mm |
| Weight | ~0.4 kg |
| Environmental Rating | IP20 indoor use |
| Diagnostics Support | Real-time operational and status diagnostics via controller interface |
| Signal Isolation | Galvanic isolation between fieldbus and control network |
| Mechanical Robustness | Resistant to vibration and industrial shocks |
| Scalability | Supports phased expansion of distributed I/O networks |
FAQ
Q1: Which systems are compatible with CI810V2?
It integrates with ABB S800 I/O, 800xA, and Advant OCS for AF100 fieldbus communication.
Q2: How is the module powered?
CI810V2 is powered directly from the S800 I/O system backplane, eliminating external wiring.
Q3: Can it operate in harsh environments?
Yes, it works from −20°C to +60°C and 5–95% non-condensing humidity.
Q4: What mounting options exist?
The module supports DIN-rail and panel mounting for flexible installation.
Q5: Does it support scalable expansion?
Yes, the CI810V2 allows efficient integration of additional AF100 field devices.
