Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model / Part Number | CI810V1 / 3BSE008584R1 |
| Module Type | AF100 Field Communication Interface |
| Communication Protocol | AF100 fieldbus communication interface |
| System Compatibility | ABB S800 I/O, 800xA, Advant OCS |
| Function | Connects fieldbus I/O units to controller networks with AF100 protocol |
| Mounting Type | DIN‑rail mount or panel mount |
| Power Supply | Powered via S800 I/O backplane (no external supply needed) |
| Operating Temperature | –20°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Humidity Range | 5% to 95% RH, non‑condensing |
| Dimensions (W×H×D) | ~142 mm × 53 mm × 65 mm |
| Weight | ~0.4 kg |
| Environmental Rating | IP20 for indoor use, industrial environment |
| Mounting Options | DIN‑rail or panel installation for versatile layout |
| Communication Speed | High‑speed AF100 fieldbus performance |
| Diagnostics Support | Operational and status diagnostics via controller interface |
| Signal Isolation | Galvanic isolation between fieldbus and system network |
| Thermal Performance | Suitable for extended industrial temperature operation |
| Mechanical Robustness | Designed for vibration and shock resistance typical to automation systems |
| Scalability | Supports expansion of distributed control networks |
FAQ
Q1: What control systems does the CI810V1 support?
The module integrates with ABB S800 I/O, 800xA, and Advant OCS automation platforms for seamless fieldbus communication.
Q2: How is this module powered?
CI810V1 receives power directly from the S800 I/O system backplane, which eliminates separate power wiring.
Q3: Can the module operate in harsh environments?
Yes, it operates over a wide temperature range from −20°C to +60°C with up to 95% non‑condensing humidity.
Q4: What mounting options are available?
The interface supports both DIN‑rail and panel mounting for flexible installation.
Q5: Does CI810V1 support scalable system expansion?
Yes, its scalable architecture enables efficient integration of additional distributed I/O devices.
