Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | AO801 |
| ABB Order Code | 3BSE020514R1 |
| Module Type | Analog Output Module |
| Number of Channels | 8 output channels per module |
| Supported Signals | 0–20 mA, 4–20 mA, 0–10 V |
| Output Load | Current: ≤ 500 Ω; Voltage: ≥ 1 kΩ |
| Accuracy | ±0.1% of full scale |
| Resolution | 16-bit digital-to-analog conversion |
| Update Time | 10 ms per channel |
| Isolation | Channel-to-backplane isolation per ABB standard |
| Operating Temperature | 0–60 °C |
| Storage Temperature | -40–85 °C |
| Relative Humidity | 5–95% non-condensing |
| Power Supply | 24 VDC, typical 3 W |
| Rack Compatibility | ABB Advant OCS / 800xA S800 racks |
| LED Indicators | Power, module status, channel fault |
| Dimensions (HxWxD) | 120 mm × 45 mm × 102 mm |
| Weight | Approx. 0.25 kg |
| Compliance | CE, UL certified |
| Maintenance | Hot-swappable; minimal routine maintenance |
| MTBF | >100,000 hours typical |
| Environment | EMI/RFI resistant for industrial conditions |
FAQ
It supports 8 independent analog output channels per module.
Q2: Which signal types can the module handle?
The module handles 0–20 mA, 4–20 mA, and 0–10 V outputs.
Q3: Is the module hot-swappable?
Yes, it can be replaced without interrupting other system operations.
Q4: Can AO801 operate in harsh industrial environments?
Yes, it is designed for high reliability under EMI/RFI and temperature extremes.
Q5: Does it integrate with both Advant OCS and 800xA systems?
Absolutely, it seamlessly integrates with ABB Advant OCS and 800xA distributed control systems.
