Overview
Configured for dual-core processing and industrial communication execution in Symphony Plus control platforms, the ABB PM876 3BDH000607R1 (PM876 Symphony Plus Controller) provides direct physical and electrical control functions through integrated CPU, memory, and network interfaces.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | PM876 3BDH000607R1 |
| Brand | ABB |
| Product Type | Symphony Plus Controller |
| Origin | Sweden |
| Weight | 2.86 kg |
| Dimensions | 27.5 x 22 x 13.5 cm |
| Operating Temp | -40 deg C to +70 deg C |
| Power Consumption | <=15 W typical |
| Processor | Dual-core ARM Cortex |
| Memory | 2 GB RAM |
| I/O Capacity | Supports up to 512 I/O points |
| Power Supply | 24 VDC |
| Ethernet Interface | 2 x 10/100/1000 Mbps Ethernet ports |
| Fieldbus Communication | PROFIBUS DP, Modbus TCP/RTU |
| Humidity | 5-95% RH non-condensing |
| Vibration | g @ 10-150 Hz |
| Tariff Code | 8537101190 |
Industrial Control Network Communication Features
The ABB PM876 integrates PLC and DCS controller functions through high-speed Ethernet communication and fieldbus connectivity. Moreover, the controller supports 2 x Gigabit Ethernet interfaces for system communication, engineering access, and distributed control data exchange.
The module uses a dual-core ARM Cortex processor with 2 GB RAM to execute application logic, process I/O data, and manage communication tasks within Symphony Plus architectures. In addition, the controller supports PROFIBUS DP and Modbus TCP/RTU interfaces for connection with field devices and remote I/O systems.
The PM876 supports I/O density scaling with capacity for up to 512 I/O points. Therefore, system designers can configure distributed control structures while maintaining standardized backplane and network communication performance.
Frequently Asked Questions
Q: What power supply does the ABB PM876 controller require?
A: The PM876 operates with a 24 VDC power supply and consumes approximately 15 W under typical operating conditions.
Q: Which communication interfaces are integrated into the PM876?
A: The controller provides two 10/100/1000 Mbps Ethernet ports and supports PROFIBUS DP and Modbus TCP/RTU communication protocols.
Q: What environmental conditions support PM876 operation?
A: The PM876 supports an operating temperature range from -40 deg C to +70 deg C and 5-95% RH non-condensing humidity conditions.
Field Installation Guidelines
Install the ABB PM876 in a compatible Symphony Plus controller rack according to the system hardware configuration requirements. Ensure that the module seats correctly into the designated slot and that all mechanical locking components are secured.
Use appropriate industrial wiring practices for power and communication connections. Keep Ethernet and fieldbus cables separated from high-voltage power conductors to reduce electromagnetic interference. Furthermore, connect cable shields according to the site grounding standard to maintain signal integrity.
Verify the 24 VDC supply polarity before energizing the controller. Confirm network addressing, firmware compatibility, and controller configuration parameters before placing the module into operational service.
