Configured for industrial cable termination interconnect handling in ABB automation system networks, the ABB NKHS03-15 (NKHS03-15 Termination Cable) provides direct physical/electrical execution.
SuffixBreakdown & Model Matrix
No validated manufacturer-defined suffix segmentation or structured model matrix is available for NKHS03-15. The designation is treated as a single ordering identifier without documented subfield decomposition.
Hardware Specifications
| Parameter | Specification |
|---|---|
| ModelBrand | ABB NKHS03-15 |
| Origin | Sweden |
| Weight | 0.4 kg |
| Dimensions | 18 cm x 17.6 cm x 2 cm |
| OperatingTemp | Not specified |
| PowerConsumption | Passive component (no active consumption specified) |
| Rated Voltage | 15 kV |
| Max System Voltage | 17.5 kV |
| Basic Impulse Level | 95 kV BIL |
| Continuous Current | 600 A |
| Fault Current | 10 kA |
| Cable Length | 15 m |
| Product Type | Termination Cable |
Industrial Control Communication Characteristics (ABB Platform Behavior Profile)
Within ABB industrial control architectures, termination cable assemblies such as NKHS03-15 are treated as passive interconnect elements within backplane-adjacent or field termination pathways. Electrical integrity is governed by impedance continuity and insulation coordination across rated system voltage levels (up to 17.5 kV max system voltage).
Deterministic signal and power pathway stability is dependent on controlled termination geometry, with emphasis on insulation coordination margins defined by 95 kV BIL withstand capability and fault withstand envelope of 10 kA. No firmware-level interaction or protocol conversion is present in the assembly.
Frequently Asked Questions
Q: Does NKHS03-15 support active signal conditioning or protocol conversion?
A: No. The assembly is passive and does not perform electrical signal processing or protocol translation.
Q: Can the termination cable be used in energized hot-swap conditions?
A: Hot-swap behavior is not applicable. Installation must be performed under de-energized conditions consistent with high-voltage termination safety procedures.
Q: Is impedance matching configurable on this cable assembly?
A: No configurable impedance elements are present. Electrical characteristics are fixed by conductor geometry and insulation design.
Field Installation Guidelines
- Ensure complete system de-energization before termination handling.
- Verify insulation clearance for rated 15 kV nominal system voltage and 17.5 kV maximum system voltage.
- Maintain controlled bending radius to avoid mechanical stress on insulation layers.
- Shielding continuity and grounding shall be bonded at designated termination points only.
- Inspect for dielectric surface contamination prior to final connection.
- Confirm mechanical strain relief at both ends of the 15 m cable run.
