Overview
The ABB DSQC266T 3HAB8802-1, identified by the base model DSQC266T, is a robot drive unit specified for motor power control within ABB robotic automation hardware. The supplied electrical data lists a three-phase AC input, a nominal DC bus, PWM motor output, and current limits. Exact compatibility with a specific ABB robot controller must be verified against the hardware configuration documentation.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DSQC266T |
| Part Number | 3HAB8802-1 |
| Brand | ABB |
| Product Type | Robot Drive Unit |
| Origin | Sweden |
| Weight | 0.58 kg |
| Dimensions | 26.8 x 14.8 x 2.8 cm (estimated shipping size) |
| Operating Temp | 0 to +45 deg C |
| Storage Temp | -25 to +70 deg C |
| Humidity | 5-95% RH, non-condensing |
| Input Voltage | 3-phase 200-480 VAC, +/-10% |
| DC Bus Voltage | 600 VDC nominal |
| Power Rating | 7.5 kW, configuration-dependent |
| Continuous Current | 12 A |
| Peak Current | 25 A for 3 seconds |
| PWM Frequency | 8 kHz |
| Control Cycle Time | 0.5 ms |
| Overload Capacity | 200% for 3 seconds |
Drive Control and Power Conversion
The supplied parameters describe a drive power stage with a three-phase AC input and a nominal 600 VDC intermediate bus. The PWM output controls motor phase voltage through switching devices, while the specified continuous and peak currents define the stated output current limits.
The 0.5 ms control cycle corresponds to a nominal 2 kHz control update rate. The 8 kHz PWM frequency describes the switching frequency, which is distinct from the control update rate.
For ABB drive integration, verify the motor type, controller compatibility, DC bus requirements, current ratings, and protection configuration against the applicable manufacturer documentation. The supplied specifications alone do not establish these compatibility details.
Frequently Asked Questions
Q: What input voltage does the DSQC266T 3HAB8802-1 require?
A: The supplied data specifies three-phase 200-480 VAC with a tolerance of +/-10%. Confirm the permitted voltage range for the exact hardware configuration before energizing the unit.
Q: What are the stated continuous and peak current ratings?
A: The supplied specifications list 12 A continuous current and 25 A peak current for 3 seconds. Confirm the applicable motor and drive operating limits before commissioning.
Q: Can the drive unit be replaced without shutting down the controller?
A: Hot replacement is not established by the supplied data. Isolate the power supply, follow the controller manufacturer’s shutdown procedure, and verify the DC bus has discharged to a safe level before removing the unit.
Field Installation Guidelines
- Power isolation: Disconnect the incoming supply and follow the equipment manufacturer’s lockout and isolation procedures before installation or removal.
- DC bus safety: Treat the DC link as hazardous until its voltage has been verified safe using an appropriately rated measuring instrument.
- Electrical connections: Check the input supply, motor terminals, protective earth, and connector assignments against the applicable ABB wiring documentation.
- Grounding and shielding: Follow the manufacturer’s grounding instructions. Keep motor power cables separated from low-level signal and feedback wiring to limit electromagnetic interference.
- Thermal management: Maintain the specified operating temperature range and provide the cooling clearances required by the actual installation.
- Commissioning: Verify motor compatibility, wiring polarity, protective devices, parameter settings, and fault indications before enabling motion.
- Dimensional verification: The supplied dimensions are identified as estimated shipping dimensions. Confirm the actual unit dimensions and mounting arrangement before planning installation.
