Overview
The ABB C1900 Series Circular Chart Recorder, also cataloged as the C1900 circular chart recorder, operates as a programmable recording device for multi-channel process signal measurement and chart-based data visualization within industrial instrumentation systems.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | C1900 Series Circular Chart Recorder |
| Brand | ABB |
| Origin | United Kingdom |
| Product Type | Circular Chart Recorders |
| Recording Capability | Up to 4 independent pen traces with configurable measurement ranges |
| Chart Rotation Speed | Adjustable from 1 hour to 32 days per revolution |
| Enclosure Protection | NEMA 4X / IP66 environmental protection |
| Mounting Options | Wall, pipe, and panel mounting configurations |
| Display | 6-digit process status display with multi-value indication and alarm information |
| Input / Output | Plug-in modules supporting recording channel expansion, calculations, and I/O functions |
| Functional Processing | Mathematical functions, mass flow calculations, totalizers, and relative humidity tables |
| Security Function | Password-protected configuration access |
| Power Consumption | Dependent on installed hardware configuration |
| Operating Temp | Dependent on selected recorder configuration |
| Weight | Dependent on enclosure and installed modules |
| Dimensions | Dependent on enclosure and mounting configuration |
ABB Industrial Control Integration and Firmware Compatibility
The ABB C1900 Series supports modular I/O expansion and configurable processing functions for industrial measurement applications. The recorder architecture allows users to assign measurement channels, calculation functions, and alarm parameters according to process requirements.
Furthermore, ABB recorder platforms use structured configuration methods to maintain compatibility between hardware options, firmware functions, and installed plug-in modules. The modular design supports I/O density scaling by adding compatible recording and calculation components without changing the basic recorder enclosure.
The C1900 also supports integration practices used across ABB instrumentation platforms, including signal conditioning, channel assignment, and controlled parameter storage for process monitoring applications.
Frequently Asked Questions
Q: How many process signals can the ABB C1900 recorder display and record simultaneously?
A: The ABB C1900 Series supports up to four independent pen traces. Each trace can be configured with individual measurement ranges for process signal recording.
Q: Does the ABB C1900 provide configurable calculation functions?
A: Yes. The recorder supports user-configurable mathematical functions, totalizers, mass flow calculations, and relative humidity table processing when corresponding functions are installed.
Q: Can the C1900 enclosure be installed in outdoor or washdown environments?
A: The C1900 enclosure provides NEMA 4X / IP66 protection, which supports installation locations requiring dust protection and resistance to water jet exposure.
Field Installation Guidelines
Install the ABB C1900 recorder on a rigid surface using the specified mounting hardware for the selected wall, pipe, or panel configuration.
Route process signal wiring separately from high-voltage power cables to reduce electrical interference. Use shielded instrumentation cables where required and connect cable shields according to the plant grounding standard.
Verify that all plug-in modules are fully seated before energizing the recorder. Confirm terminal assignments, input ranges, and configuration parameters before connecting field devices.
Maintain adequate clearance around the enclosure to allow access for chart replacement, wiring inspection, and service operations. Follow ABB installation documentation for commissioning procedures and parameter configuration.
