Overview
Configured for video signal generation in ABB automation frame systems, the ABB EXC57350001-CN (DSAV111 Communication Module) provides direct physical execution for video data output functions. The module is identified as a DSAV 111 Video Board with a frame rate specification of 61.2 Hz and supports dedicated display-related hardware operations.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DSAV111 |
| Full Order Model | EXC57350001-CN / 57350001-CN |
| Brand | ABB |
| Product Type | Communication Module / Video Board |
| Weight | 0.395 kg |
| Shipping Weight | 0.4 kg |
| Dimensions | 25.4 x 5.1 x 25.4 cm |
| Frame Rate | 61.2 Hz |
| Hardware Function | Video signal generation and display interface processing |
| Product Classification | Communication Module |
Industrial Control Bus and Video Interface Characteristics
The ABB DSAV111 operates as a dedicated communication hardware component within ABB industrial control platforms. Moreover, the module processes video generation tasks through defined hardware interfaces rather than executing general-purpose application logic.
The DSAV111 belongs to ABB PLC and DCS hardware families that require controlled module integration with system backplanes. Therefore, engineers should verify backplane compatibility, firmware flash compatibility, and communication architecture requirements before installation.
In addition, ABB module designs typically maintain controlled signal transmission paths to support stable communication between hardware components. The DSAV111 uses a fixed hardware function set for video board operation and does not provide user-configurable I/O channel expansion.
Frequently Asked Questions
Q: What is the primary function of the ABB DSAV111 module?
A: The DSAV111 functions as a video board module that generates video signals for compatible ABB automation hardware configurations.
Q: Does the DSAV111 provide standard PLC I/O channels?
A: No. The DSAV111 is classified as a communication module and video board. It does not operate as a digital or analog field I/O module.
Q: What installation compatibility should be checked before replacing a DSAV111 module?
A: Engineers should verify the ABB system frame configuration, module slot compatibility, communication interface requirements, and firmware compatibility before replacement.
Field Installation Guidelines
Install the ABB DSAV111 only in the designated ABB equipment frame and confirm mechanical alignment before insertion.
Use proper grounding practices for connected control equipment to reduce electrical interference during video signal transmission. Keep signal cables separated from high-voltage power wiring and follow the cabinet manufacturer’s routing requirements.
Before commissioning, inspect module seating, connector condition, and communication links. Verify that the replacement module matches the required DSAV111 hardware configuration and system revision.
