Overview
Configured for program execution, process data handling, and controller communication in ABB AC500 systems, the ABB PM582 (PM582 Processor Module) provides direct electrical execution. The module integrates CPU resources, communication interfaces, memory functions, and local controller services for data exchange between application programs and connected I/O assemblies.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | PM582 |
| Brand | ABB |
| Product Series | AC500 |
| Product Type | Processor Module |
| Product ID | 1SAP140200R0201 |
| User Program Memory | 128 KB |
| Serial Interfaces | 2 x RS232/485 |
| Display | Integrated Display |
| Rated Voltage | 24 VDC |
| Supply Voltage Range | 20.4 to 28.8 VDC |
| Protection Rating | IP20 |
| Operating Temp | 0 to 60 deg C |
| Storage Temp | -40 to 70 deg C |
| Dimensions | 76 x 67.5 x 62 mm |
| Weight | 0.137 kg |
| Origin | Germany / Finland |
| Power Consumption | Not specified in available documentation |
Firmware Flash Compatibility
The PM582 processor executes user applications, manages memory allocation, and coordinates communication tasks within the AC500 controller platform. In addition, the processor exchanges operational data with local and expansion I/O modules through the controller architecture.
Furthermore, firmware versions influence communication behavior, hardware recognition, and engineering software interoperability. Before loading an application or upgrading a controller, engineers should verify firmware compatibility across all installed system components. As a result, consistent firmware management helps maintain stable operation throughout the controller lifecycle.
Frequently Asked Questions
Q: What is the primary function of the PM582 processor module?
A: The processor executes user control programs, manages memory resources, and coordinates communication between connected AC500 hardware components.
Q: Can firmware versions affect communication and hardware compatibility?
A: Yes. Different firmware revisions may introduce changes to hardware support, communication services, and engineering software interaction. Therefore, engineers should verify compatibility before performing updates.
Q: Does the documentation specify hot-swapping capability for the PM582?
A: No. The available documentation does not define a hot-swap procedure. Consequently, technicians should remove controller power before installing or replacing the processor module.
Field Installation Guidelines
- First, mount the processor module securely on the designated DIN rail and verify proper mechanical engagement.
- Next, confirm that the incoming supply voltage remains within the specified 20.4 to 28.8 VDC operating range.
- Additionally, route serial communication cables separately from motor power wiring and other high-current conductors.
- During installation, connect cable shields according to plant grounding practices and maintain a continuous protective earth path.
- Before startup, inspect all terminal connections, module interfaces, and expansion hardware connections.
- Furthermore, verify firmware compatibility between the processor and installed engineering software.
- Finally, perform controller diagnostics and communication checks before placing the system into operation.
