Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 560CMU05 |
| ABB Part Number | 1KGT012700R0002 |
| Module Type | Communication Unit for RTU560 |
| Supported Protocols | Modbus RTU, DNP3, IEC 60870-5-101/104 |
| Digital Inputs/Outputs | Configurable digital I/Os for monitoring and control |
| Analog Inputs/Outputs | Supports analog data exchange channels |
| Communication Ports | RS-232, RS-485, Ethernet |
| Data Transfer Rate | Up to 115.2 kbps for serial connections |
| Operating Temperature | -20°C to 60°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Mounting | Panel-mounted or DIN-rail |
| Dimensions (HxWxD) | Approx. 120 mm x 35 mm x 200 mm |
| Weight | Approx. 0.7 kg |
| Reliability / Lifetime | Designed for long-term operation in industrial environments |
FAQ
A1: Yes, it is specifically designed to work seamlessly with ABB RTU560 remote terminal units.
Q2: What communication protocols are supported?
A2: It supports Modbus RTU, DNP3, and IEC 60870-5-101/104 protocols.
Q3: Can it operate in harsh industrial environments?
A3: Yes, the unit works reliably from -20°C to 60°C with 5–95% non-condensing humidity.
Q4: How many communication ports are available?
A4: The module includes RS-232, RS-485, and Ethernet ports for versatile connectivity.
Q5: Does it provide diagnostics for monitoring?
A5: Yes, it includes built-in diagnostic features for efficient monitoring and troubleshooting.
