Overview
Specification
| Category | Specification |
|---|---|
| Manufacturer | ABB (ASEA Brown Boveri) |
| Model / Part Number | SDCS-COM-1 / 3BSE005028R0001 |
| Module Type | Drives Link / Communication Board |
| Function | Enables high-speed communication between ABB drives and control modules |
| Supply Voltage | 9–36 VDC (nominal 24 VDC) |
| Power Consumption | < 4 W |
| Isolation | 1500 V DC between power and communication circuits |
| Reverse Polarity Protection | Yes |
| Relay Alarm Output | Provides alert on link or power failure (Contact rating: DC 48 V / 1 A) |
| Primary Interface | Fiber-optic link for high-speed, interference-free communication |
| Supported Protocols | ABB proprietary drive-link; confirm system compatibility for Modbus, CANopen, Ethernet, OPC-UA |
| Operating Temperature | –20 °C to +60 °C (some variants up to –10 °C to +70 °C) |
| Environmental Protection | Designed for industrial electrical noise, temperature fluctuations, and surge conditions |
| Mounting | Rack-mounted or panel-mounted in control cabinets |
| Dimensions | Approx. 132 × 105 mm |
| Net Weight | ~0.24–0.5 kg |
| Compliance / Standards | Industrial-grade insulation and protection; suitable for heavy-duty automation environments |
FAQ
A1: It enables reliable communication between ABB drive modules, ensuring efficient system coordination.
Q2: Can it operate under harsh industrial conditions?
A2: Yes, it withstands temperature extremes and electrical disturbances while maintaining performance.
Q3: Is the SDCS-COM-1 compatible with all ABB drives?
A3: It integrates seamlessly with compatible ABB drive and automation modules for efficient networking.
Q4: How does this board improve system uptime?
A4: Its stable communication and error diagnostics reduce operational interruptions and enhance reliability.
