Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 1MRK002266-AAR00 |
| Module Type | Optical Ethernet Module |
| Interface | Optical fiber, SC connectors |
| Data Rate | 100 Mbps / Full-duplex |
| Wavelength | 1310 nm / 1550 nm (depending on fiber type) |
| Transmission Distance | Up to 20 km with single-mode fiber |
| Supported Protocols | Ethernet, TCP/IP, Modbus TCP |
| Power Supply | 24 VDC ±10% |
| Power Consumption | Typical: 4 W / Maximum: 6 W |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 10–95% non-condensing |
| LED Indicators | Link status, activity, and power |
| Mounting | DIN rail or panel mount |
| Dimensions (WxHxD) | 110 mm × 90 mm × 35 mm |
| Weight | Approx. 0.6 kg |
| Isolation | Optical isolation between input and output circuits |
| Compliance | CE, RoHS |
FAQ
A1: It provides high-speed, reliable optical communication between PLC systems and peripheral devices.
Q2: Can this module reduce electrical interference in industrial environments?
A2: Yes, its robust optical interface actively minimizes interference, ensuring stable signal integrity.
Q3: Is the module compatible with existing ABB PLC systems?
A3: Yes, it seamlessly integrates with ABB PLC networks and supports efficient data transfer.
Q4: What is the maximum distance supported for fiber connections?
A4: The module supports long-distance optical fiber links, allowing scalable network expansion.
Q5: How does this module improve industrial communication reliability?
A5: It ensures consistent data transfer, reduces downtime, and maintains secure communication across networks.
Q6: Can this module be used in electrically noisy environments?
A6: Absolutely, its design actively reduces signal interference and maintains performance in harsh conditions.
