Overview
Specification
| Specification | Details |
|---|---|
| Model Number | 1MRK000614-ABR00 |
| Module Type | Binary Output Module |
| Output Channels | 16 discrete outputs |
| Output Type | Relay / Digital switching |
| Switching Voltage | Up to 250 VAC / 30 VDC |
| Switching Current | Maximum 2 A per channel |
| Response Time | ≤ 5 ms |
| Isolation | Optical isolation per channel |
| Input Voltage | 24 VDC |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5–95%, non-condensing |
| Mounting | DIN rail or panel mount |
| Dimensions (H x W x D) | 120 mm x 50 mm x 160 mm |
| Weight | Approximately 1.1 kg |
| Compliance | CE, UL, IEC standards |
| Diagnostics | LED indicators for channel status |
FAQ
A1: It provides 16 discrete outputs for controlling relays, actuators, and field devices.
Q2: What is the maximum switching voltage and current?
A2: Each output can switch up to 250 VAC or 30 VDC at a maximum of 2 A.
Q3: Can it operate in standard industrial temperatures?
A3: Yes, it operates reliably from 0°C to 55°C under typical industrial conditions.
Q4: What mounting options are available for installation?
A4: The module supports DIN rail or panel mounting for flexible integration.
Q5: Does the module provide any diagnostic features?
A5: Yes, LED indicators show channel status and aid troubleshooting.
Q6: Is it compatible with ABB Advant OCS systems?
A6: Absolutely, it integrates seamlessly with Advant OCS and related modules.
