Overview
Specification
| Specification | Details |
|---|---|
| Model Number | 1MRK000173-BCr00 |
| Module Type | Binary Input/Output Module |
| Input Channels | 16 discrete inputs |
| Output Channels | 16 discrete outputs |
| Output Type | Relay / Digital switching |
| Input Voltage | 24 VDC |
| Switching Voltage | Up to 250 VAC / 30 VDC |
| Switching Current | Maximum 2 A per output channel |
| Response Time | ≤ 5 ms |
| Isolation | Optical isolation per channel |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5–95%, non-condensing |
| Mounting | DIN rail or panel mount |
| Dimensions (H x W x D) | 120 mm x 50 mm x 160 mm |
| Weight | Approximately 1.1 kg |
| Compliance | CE, UL, IEC standards |
| Diagnostics | LED indicators for input/output status |
FAQ
A1: It offers 16 discrete inputs and 16 discrete outputs for versatile system control.
Q2: What is the maximum switching voltage and current?
A2: Each output can switch up to 250 VAC or 30 VDC at a maximum of 2 A.
Q3: Can it operate in standard industrial temperature ranges?
A3: Yes, it functions reliably between 0°C and 55°C under normal industrial conditions.
Q4: What mounting options are available for installation?
A4: The module supports both DIN rail and panel mounting for flexible integration.
Q5: Does the module offer diagnostics?
A5: Yes, LED indicators provide input/output status for quick troubleshooting.
Q6: Is it compatible with ABB Advant OCS systems?
A6: Absolutely, it integrates seamlessly with ABB Advant OCS networks and related modules.
