Overview
The ABB TK811V150, also cataloged as the TK811V plastic optical fiber cable, operates as a dedicated hardware component for optical ModuleBus communication within the ABB Advant S800 I/O platform. The cable provides a duplex plastic optical fiber link with latching duplex connectors for point-to-point optical module interconnection.
Suffix Breakdown & Model Matrix
The available documentation identifies TK811V150 as a fixed ordering model corresponding to a predefined cable assembly. No official suffix decoding or configurable model matrix is specified by the manufacturer.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | TK811V150 |
| Spare Model | 3BSC950107R3 |
| Brand | ABB |
| Product Family | ABB Advant S800 I/O |
| Product Type | ModuleBus Plastic Optical Fiber Cable |
| Cable Type | Duplex plastic optical fiber (POF) |
| Connector Type | Latching duplex connector |
| Cable Length | 15 m |
| Communication Function | Optical ModuleBus connection |
| Weight | 0.125 kg |
| Dimensions | Not specified by manufacturer |
| Operating Temp | Not specified by manufacturer |
| Power Consumption | Passive component; no electrical power consumption |
| Origin | ABB (manufacturing origin not specified) |
| Shipping Reference | Webster, NY, USA |
Firmware and ModuleBus Compatibility
As a passive optical communication cable, the TK811V150 does not contain firmware or programmable electronics. Firmware compatibility is therefore determined by the connected ABB Advant S800 I/O communication modules rather than by the cable itself.
The duplex plastic optical fiber construction supports the optical ModuleBus physical layer used within compatible ABB Advant S800 I/O assemblies. Correct connector orientation, minimum bend radius, and secure latching should be maintained to preserve optical signal integrity.
Frequently Asked Questions
Q: Does the TK811V150 require firmware updates?
A: No. The cable is a passive optical component and contains no firmware or programmable electronics.
Q: Can the cable be connected while the system is energized?
A: The cable itself contains no electrical circuitry. Connection or disconnection should follow the installation procedure specified for the associated ABB S800 I/O hardware to prevent communication interruption.
Q: Is the cable compatible with electrical ModuleBus interfaces?
A: No. The TK811V150 is designed for optical ModuleBus connections using duplex plastic optical fiber and matching latching duplex connectors.
Field Installation Guidelines
- Verify that both connected modules support optical ModuleBus communication before installation.
- Route the fiber cable separately from high-power conductors to reduce the possibility of mechanical damage.
- Avoid excessive bending, twisting, crushing, or tensile loading of the plastic optical fiber during installation.
- Ensure that both duplex connectors are fully latched before system commissioning.
- Keep optical connector end faces clean and protected from dust and contamination before connection.
- Secure the cable with appropriate strain relief to prevent connector movement caused by vibration or maintenance activity.
