Overview
Specification
| Parameter | Value |
|---|---|
| Product Model | SB510 |
| Part Number | 3BSE000860R1 |
| System Platform | ABB Advant OCS |
| Function | Backup Power Supply Module |
| Input Voltage | 110 / 230 VAC (selectable) |
| Input Voltage Range | 100–120 VAC / 200–240 VAC |
| Input Frequency | 47–63 Hz |
| Output Voltage | 24 VDC (regulated) |
| Output Capacity | 5 A typical (module dependent) |
| Hold-Up Capability | Maintains output during AC dropouts |
| Protection Features | Overload, overvoltage, thermal |
| Status Monitoring | Front-panel indicators |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | –25°C to +70°C |
| Cooling Method | Natural convection |
| Installation Type | Fits Advant OCS rack, module format |
| Dimensions | Standard OCS PSU module size |
| Compliance | CE, industrial automation standards |
FAQ
A1: It is designed specifically for the ABB Advant OCS control system.
Q2: Does the SB510 accept both 110V and 230V AC input?
A2: Yes, it supports global voltage ranges, which simplifies installation in international plants.
Q3: What output voltage does the module provide?
A3: It delivers a stable 24 VDC output to the control system.
Q4: Can the SB510 protect downstream modules during voltage dips?
A4: Yes, it provides hold-up capability that stabilizes output during primary AC disturbances.
Q5: How difficult is installation?
A5: Technicians can install it easily by plugging it into the Advant OCS rack and wiring the AC input.
Q6: What typical applications use this backup power supply?
A6: It is widely used in power generation, petrochemical operations, industrial manufacturing, and process automation.
