Overview
Specification
| Parameter / Attribute | Specification / Details |
|---|---|
| Brand / Manufacturer | ABB |
| Model / Part Number | SR511 / 3BSE000863R1 |
| Module Type | Advant OCS Power Regulator |
| Input Voltage | 24 V DC nominal |
| Output Voltage | 24 V DC and 5 V DC regulated |
| Output Current | 24 V DC: up to 2 A; 5 V DC: up to 1 A |
| Load Regulation | ±2% typical |
| Line Regulation | ±1% typical |
| Ripple & Noise | <50 mV peak-to-peak |
| Mounting / Installation Method | Rack-mounted in Advant OCS subracks |
| Operating Temperature Range | 0°C to 55°C |
| Storage Temperature Range | –20°C to 70°C |
| Dimensions (WxHxD) | Approx. 100 × 120 × 35 mm |
| Weight | Approx. 0.4 kg |
| Protection / Compliance | Industrial-grade design for indoor cabinet installation; meets standard ABB specifications |
FAQ
A1: It provides regulated 24 V DC and 5 V DC outputs for Advant OCS modules.
Q2: What is the maximum output current?
A2: 24 V output supports up to 2 A; 5 V output supports up to 1 A.
Q3: Can it operate in standard Advant OCS racks?
A3: Yes, the compact design allows easy installation into standard Advant subracks.
Q4: What is the operating temperature range?
A4: It operates reliably from 0°C to 55°C in indoor industrial environments.
