Overview
It organizes field wiring between analog I/O modules and plant instrumentation, therefore improving signal clarity and system maintainability.
Moreover, the NTAM01 simplifies cabinet layouts by consolidating multiple analog terminations into a structured interface.
Control engineers rely on this unit when stable analog signal routing directly influences loop accuracy and operational reliability.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB (Bailey Controls) |
| Product Model | NTAM01 |
| Product Type | Analog Master Termination Unit |
| Compatible Systems | ABB Bailey Infi 90, Net 90 |
| Primary Function | Centralized analog signal termination |
| Supported Signals | Analog input and analog output signals |
| Signal Types | Low-level industrial analog signals (per connected I/O modules) |
| Connection Method | Screw terminal blocks |
| Termination Role | Master termination between field wiring and I/O modules |
| Electrical Isolation | Designed to maintain analog signal integrity |
| Power Requirement | Passive device, no external power required |
| Mounting Location | Control cabinet or termination panel |
| Mounting Style | Standard Bailey termination mounting |
| Operating Temperature Range | 0 °C to +60 °C (32 °F to 140 °F) |
| Storage Temperature Range | −40 °C to +85 °C (−40 °F to 185 °F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Mechanical Construction | Industrial-grade materials for continuous service |
| Typical Weight | Approximately 1.0 kg (2.2 lbs) |
FAQ
A1: The NTAM01 provides centralized termination for analog input and output signals in Infi 90 systems.Q2: Does the NTAM01 perform signal conditioning or conversion?
A2: No, signal conditioning occurs within the associated analog I/O modules.
Q3: Does the NTAM01 require an external power supply?
A3: No, the unit operates passively and requires no power.
Q4: Which types of analog signals can the NTAM01 support?
A4: It supports low-level industrial analog signals defined by connected I/O modules.
Q5: Is the NTAM01 suitable for continuous industrial operation?
A5: Yes, ABB designed it for long-term use in demanding control environments.
Q6: How does the NTAM01 improve system maintenance?
A6: Organized terminals and clear labeling reduce diagnostic time and wiring mistakes.
