Overview
It establishes a unified time reference, therefore ensuring consistent time stamping across control, event, and operator systems.
Moreover, the module synchronizes distributed system components, supporting accurate diagnostics and reliable historical data analysis.
Engineers deploy the INTKM01 in critical installations where precise time coordination directly affects operational visibility and accountability.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB (Bailey Controls) |
| Product Model | INTKM01 |
| Product Type | Time Keeper Master Module |
| Compatible Systems | ABB Bailey Infi 90 and Net 90 |
| Primary Function | Centralized system time synchronization |
| Time Distribution Method | Infi 90 internal system bus |
| Supported Functions | Alarm time stamping, SOE coordination, historical data alignment |
| Clock Accuracy | High-stability internal time reference |
| Time Resolution | Millisecond-level synchronization |
| Redundancy Support | Compatible with redundant system architectures |
| Communication Interface | Bailey Infi 90 backplane interface |
| Data Scope | System-wide time reference for all connected modules |
| Power Supply | Provided by Infi 90 / Net 90 system backplane |
| Typical Power Consumption | Approximately 8–10 W |
| Installation Location | Standard Bailey control system rack |
| Operating Temperature Range | 0 °C to +60 °C (32 °F to 140 °F) |
| Storage Temperature Range | −40 °C to +85 °C (−40 °F to 185 °F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Industrial Rating | Designed for continuous industrial duty |
| Module Weight | Approximately 1.3 kg (2.9 lbs) |
FAQ
A1: The INTKM01 provides a centralized master time reference for Infi 90 and Net 90 control systems.
Q2: Which systems are compatible with the INTKM01?
A2: It is designed specifically for ABB Bailey Infi 90 and Net 90 platforms.
Q3: Why is time synchronization important in control systems?
A3: Accurate time alignment ensures reliable alarm analysis, event reconstruction, and historical data correlation.
Q4: Does the INTKM01 support sequence of events systems?
A4: Yes, it provides the master time reference required for accurate SOE recording.
Q5: Can the INTKM01 operate continuously in industrial environments?
A5: Yes, ABB designed it for nonstop operation under harsh industrial conditions.
Q6: Is the INTKM01 suitable for safety-critical applications?
A6: Yes, consistent time stamping supports investigations, audits, and safety compliance requirements.
