Overview
Specification
| Parameter | Specification |
|---|---|
| Product Type | Extension Memory / Expansion Module |
| Manufacturer | ABB |
| Model Number | DSQC323 / 3HAB5956‑1 |
| Memory Capacity | 8 MB expansion for controller memory |
| Primary Function | Increases controller storage and improves program execution |
| Compatibility | ABB IRC5 and other ABB robotic / control platforms |
| Interface Type | Plug‑and‑play connection to main control unit |
| Operating Voltage | Typically 12–24 V DC |
| Power Consumption | ~1.45 W typical |
| I/O Support (optional context) | 16 digital inputs & 16 digital outputs (in certain configurations) |
| Operating Temperature | ‑20 °C to +60 °C |
| Storage Temperature | ‑55 °C to +85 °C |
| Humidity Range | Industrial non‑condensing humidity levels |
| Enclosure Rating | IP20 suitable for control cabinet environments |
| Mounting Type | Panel or cabinet mounting (modular integration) |
| Dimensions (Approx.) | 127 mm × 152 mm × 102 mm |
| Weight | ~0.3 kg net weight |
| Country of Origin | Sweden |
| Certifications | Meets ABB industrial quality and control system reliability standards |
| Warranty | Typically 12 months (supplier dependent) |
| Special Features | Plug‑and‑play upgradability, optimized for high‑speed data access |
FAQ
A1: It supports ABB robot controllers, drives, and industrial automation modules.
Q2: What is the memory capacity of this board?
A2: The DSQC323 provides 4 MB of additional memory for program storage.
Q3: How is the board installed?
A3: It mounts directly into ABB control modules or designated panel slots.
Q4: Can it operate in high-temperature environments?
A4: Yes, it supports operating temperatures from 0°C to +55°C.
Q5: Does ABB provide support and documentation?
A5: Yes, ABB offers manuals, configuration guides, and technical support.
