Overview
It features eight universal input channels, therefore allowing flexibility in connecting various sensor types such as RTDs, thermocouples, or 4–20 mA signals.
Moreover, AI830 integrates directly into ABB control racks, minimizing installation complexity and wiring effort.
Engineers rely on this module to ensure accurate process monitoring and robust data acquisition in industrial automation environments.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | AI830 |
| ABB Order Code | 3BSE008518R1 |
| Product Type | Analog Input Module (1×8 channels) |
| Compatible Systems | ABB Advant OCS, ABB 800xA |
| Number of Channels | 8 universal input channels |
| Supported Signal Types | RTD, thermocouple, 0–10 V, 4–20 mA |
| Measurement Accuracy | ±0.1% of full scale typical |
| Input Impedance | 10 kΩ for voltage, 250 Ω for current |
| Isolation | Channel-to-channel galvanic isolation |
| Diagnostics | Status LEDs for channel and module health |
| Mounting | Rack-mounted within control cabinets |
| Environmental Rating | Industrial temperature and vibration tolerance |
| Maintenance | Minimal, periodic inspection recommended |
| Typical Application | Process monitoring, control, and data acquisition |
FAQ
A1: The AI830 provides accurate measurement of analog signals for Advant OCS and 800xA systems.
Q2: How many channels does AI830 support?
A1: The module supports eight universal analog input channels for various signal types.
Q3: Which signal types are compatible with AI830?
A1: RTDs, thermocouples, 0–10 V, and 4–20 mA signals are supported.
Q4: Does AI830 provide diagnostic feedback?
A1: Yes, status LEDs indicate channel health and module status for easy troubleshooting.
Q5: Is the module suitable for continuous industrial operation?
A1: Yes, ABB designed AI830 for reliable operation in demanding industrial environments.
