Overview
The ABB XVC768102 (3BHB007211R0102) is identified as an industrial current measurement scaling module associated with ABB drive equipment. It processes current feedback signals for drive control and monitoring. However, the exact module designation and electrical specifications require confirmation before installation or replacement. Therefore, verify the complete part number and drive configuration before selecting this component.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | XVC768102 |
| Brand | ABB |
| Part Number | 3BHB007211R0102 |
| Product Type | Current Measurement Scaling Module |
| Associated Drive System | ACS6000 |
| Associated Drive Power Class | 7 MVA |
| Measurement Range | -2865 to +2865 A |
| Rated Current (RMS) | 980 A |
Function and Application
The XVC768AE102 designation identifies a current measurement scaling module associated with the ABB ACS6000 drive system. The module processes current feedback signals so that the drive control system can use them for monitoring and control. However, confirm that the XVC768102 marking corresponds to this exact configuration before applying these specifications.
Configuration and Selection
Before ordering a replacement, compare the module label, complete part number and installed drive configuration. In addition, check the current measurement range and rated-current requirements against the original equipment documentation. Similar XVC768 model numbers do not automatically indicate electrical or functional compatibility.
Frequently Asked Questions
Q: What is the main function of the ABB XVC768102?
A: The associated XVC768AE102 designation identifies a current measurement scaling module. However, confirm the exact model designation before applying this function to the XVC768102 unit.
Q: What does the 7 MVA rating mean?
A: The 7 MVA figure refers to the associated drive power class, not the module’s own power consumption. Verify that this rating matches the installed drive configuration.
Q: Can I replace this module with another XVC768 variant?
A: Do not assume direct compatibility. Instead, compare the full part number, measurement range and drive configuration before installing a replacement.
