Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | REPL-02 |
| Brand | ABB |
| Product Type | Ethernet POWERLINK Adapter Module |
| Origin | Sweden |
| Weight | 0.22 kg |
| Dimensions | 4.5 x 10.5 x 12 cm (estimated shipping size) |
| Operating Temp | -25 deg C to +60 deg C |
| Humidity | 5-95% RH, non-condensing |
| Supply Voltage | 24 VDC |
| Power Consumption | <=5 W |
| Isolation | 1500 V AC |
| Communication Protocol | Ethernet POWERLINK |
| Cycle Time | <=200 us |
| Tariff Code | 8537101190 |
| Shipment Location | Xiamen, China |
Ethernet POWERLINK Communication Interface
The ABB REPL-02 operates as an Ethernet POWERLINK adapter module for deterministic industrial communication. It manages cyclic data exchange with connected automation components and supports communication cycle times of <=200 us.
In addition, the module uses a 24 VDC supply input and maintains electrical isolation up to 1500 V AC. Therefore, it supports integration into industrial control environments where signal separation and communication stability are required.
For ABB automation platforms, the module aligns with industrial network requirements through Ethernet-based communication architecture. It supports structured data transmission between control components without converting the communication protocol.
Frequently Asked Questions
Q: What communication protocol does the ABB REPL-02 support?
A: The ABB REPL-02 supports the Ethernet POWERLINK protocol for deterministic industrial network communication.
Q: What power supply does the REPL-02 require?
A: The module requires a 24 VDC supply voltage and operates with power consumption of <=5 W.
Q: Does the REPL-02 provide electrical isolation?
A: Yes. The module provides 1500 V AC isolation between electrical circuits to support industrial installation requirements.
Field Installation Guidelines
- Install the REPL-02 in a suitable industrial control enclosure with protection from conductive contamination and excessive vibration.
- Connect the 24 VDC power supply using properly rated industrial wiring and verify polarity before energizing the module.
- Route Ethernet POWERLINK communication cables separately from high-voltage power cables to reduce electromagnetic interference.
- Use appropriate cable shielding and connect shield layers according to the system grounding design.
- Confirm network addressing, communication configuration, and controller compatibility before placing the module into operation.
- Maintain sufficient airflow around installed equipment to support operation within the specified temperature range.
