Overview
ABB RET670 is a high-performance transformer protection and control relay designed for critical power system applications.
Moreover, it delivers advanced differential protection, and it ensures fast fault detection while maintaining secure substation operation.
In addition, ABB RET670 supports IEC 61850 communication, and it enables seamless integration into modern digital substation architectures.
Functional Highlights
The relay combines multifunctional protection, advanced control, and real-time monitoring, and it significantly enhances grid reliability.
Moreover, it offers adaptive protection settings, and it improves operational flexibility across varying network conditions efficiently.
Therefore, engineers use intuitive configuration tools, and they simplify commissioning while reducing overall setup time significantly.
Specification
| Category | Specification |
|---|---|
| Model | ABB RET670 |
| Order Number | 1MRK00008-HB |
| Product Type | Transformer Protection and Control Relay |
| Application Scope | High-voltage transformer protection systems in utility and industrial substations |
| Protection Principle | Numerical multi-function protection relay with adaptive logic control |
| Primary Protection Functions | Transformer differential protection, restricted earth fault, overcurrent protection, earth fault protection, thermal overload supervision |
| Backup Protection Functions | Time-delayed overcurrent, directional earth fault, breaker failure protection support |
| Communication Protocols | IEC 61850 (Edition 1 & 2), Modbus RTU, DNP3 |
| Communication Features | GOOSE messaging, horizontal communication, SCADA integration support |
| Engineering Tool | ABB PCM600 protection and control IED manager |
| Configuration Interface | Local HMI and PCM600 software-based parameter setting |
| Rated Auxiliary Voltage | 48–250 V DC (wide-range power supply input) |
| Power Consumption | Typically low-power digital relay design for substation efficiency |
| Mounting Type | 19-inch panel-mounted modular design |
| Installation Method | Flush mounting in control and protection panels |
| Operating Temperature Range | -25°C to +70°C for harsh substation environments |
| Storage Temperature Range | -40°C to +85°C for extended logistics handling |
| Sampling Rate | High-speed digital sampling for fast fault detection and trip execution |
| Event Recording | Fault records, disturbance recorder (DR), and sequence of events (SOE) logging |
| Time Synchronization | IRIG-B / SNTP / IEC 61850 time synchronization support |
| Expandability | Supports modular I/O expansion for flexible system design |
| Cyber Security | Role-based access control and secure communication protocols support |
FAQ
It is primarily used for transformer protection, control, and monitoring in high-voltage power networks and substations. Therefore, operators rely on it to ensure stable and safe grid performance.
Q2: Does ABB RET670 support IEC 61850 communication?
Yes, it fully supports IEC 61850, and it enables seamless integration into modern digital substation automation systems. Moreover, engineers can achieve efficient communication between intelligent electronic devices.
Q3: Which protection functions are included in RET670?
It includes transformer differential protection, overcurrent protection, earth fault detection, and thermal monitoring functions. In addition, these functions work together to improve system reliability and fault response speed.
Q4: What industries commonly use this relay?
It is widely applied in utilities, renewable energy plants, and heavy industrial power distribution systems. Therefore, it supports both conventional grids and modern energy infrastructure effectively.
Q5: What configuration tools are required?
Engineers use ABB PCM600 software for engineering, configuration, and parameter management of the RET670 relay. Moreover, this tool simplifies setup and helps reduce commissioning time significantly.
