Overview
Configured for operator interface control in ABB Advant OCS and 800xA distributed control systems, the ABB PP865A (base model 3BSE042236R2) provides direct physical display execution and local data input/output handling.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model Brand | ABB PP865A 3BSE042236R2 |
| Origin | Sweden |
| Weight | 2.04 kg |
| Dimensions | 302 mm x 230 mm x 60 mm |
| Operating Temp | -20 degC to +70 degC (Storage) |
| Power Consumption | +24 V DC (20 – 30 V DC), 3-pin jack connection block |
| Display Type | 15-inch TFT HMI panel |
| Touch Screen | Polyester on glass, 1 million finger touch operations |
| Enclosure Material | Powder-coated aluminum |
Backplane Bus Communication Velocity Licenses
The PP865A executes deterministic communication via the CEX-Bus backplane interface. Firmware flash compatibility is governed by the specific license key installed on the processor unit. Data exchange rates are bound by the bus arbitration cycle time, requiring strict adherence to the module’s firmware revision matrix to prevent protocol stack rejection during system boot-up.
Frequently Asked Questions
Q: What is the procedure for replacing the real-time clock battery?
A: The internal rechargeable battery requires no field replacement. If the panel loses power for extended periods, the RTC will reset. Recalibration must be performed via the Control Builder engineering station.
Q: Are the D-sub connectors compatible with standard industrial cabling?
A: Yes. The unit utilizes a 25-pin chassis-mounted female D-sub and a 9-pin male D-sub, both fitted with standard 4-40 UNC locking screws to ensure mechanical retention against vibration.
Field Installation Guidelines
Mount the panel into the cabinet cutout using the provided clamps. Ensure the gasket seal is intact to maintain the IP rating. Tighten connector locking screws to 0.5 Nm torque. Route the 24 V DC power supply cable separately from high-voltage AC lines to minimize electromagnetic interference. Ground the chassis directly to the enclosure earth bar using a minimum 2.5 mm^2 green-yellow conductor.
