Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 70EA01A-E |
| Module Type | Procontrol P13 Analog Input Module |
| Input Channels | 16 analog channels (voltage/current configurable) |
| Input Range | 0–10 V, ±10 V, 0–20 mA, 4–20 mA |
| Resolution | 16-bit A/D conversion |
| Response Time | ≤ 10 ms per channel |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Power Supply | 24 V DC ±10% |
| Mounting | DIN rail / Panel mount |
| Diagnostics | LED status indicators per channel |
| Communication Interface | ABB Procontrol P series bus compatible |
| Dimensions (H × W × D) | 130 mm × 30 mm × 150 mm (approx.) |
| Protection Rating | IP20 (standard for industrial modules) |
FAQ
A: It supports 16 configurable analog input channels for voltage or current signals.
Q: What is the input signal range for this module?
A: The module supports 0–10 V, ±10 V, 0–20 mA, and 4–20 mA inputs.
Q: Can it operate under extreme temperatures?
A: Yes, it functions reliably between -20°C and +60°C in industrial environments.
Q: Is it compatible with other ABB Procontrol P series modules?
A: Yes, it integrates seamlessly with ABB P series controllers and modules.
