Overview
Engineers benefit from robust 1000 Vrms isolation between bus, ground, and channels, ensuring reliable operation under industrial conditions. The TSXAEY800 consumes 270 mA at 5 V DC and features a SUB-D 25 connector for easy wiring. With a compact format and weight of only 0.31 kg, it integrates seamlessly into Modicon Premium systems.
Specification
| Specification | Value |
|---|---|
| Range of Product | Modicon Premium |
| Product Type | Analog Input Module |
| Analog Input Channels | 8 |
| Supported Input Types | ±10 V, 0–10 V, 0–5 V, 1–5 V, 0–20 mA, 4–20 mA |
| Conversion Resolution | 12 bits |
| Nominal Read Cycle | 27 ms |
| Fast Read Cycle | 3 ms + 3 ms × number of channels used |
| Isolation Voltage | 1000 Vrms (bus, channels, ground) |
| Current Consumption | 270 mA at 5 V DC |
| Connector Type | 1 × SUB-D 25 |
| Protection | Overvoltage ±30 V, overcurrent ±30 mA |
| Net Weight | 0.31 kg |
| Operating Temperature | 0…60 °C |
| Storage Temperature | -25…70 °C |
| Relative Humidity | 10–95 % (operation), 5–95 % (storage) |
| Altitude Rating | 0–2000 m |
| Certifications | CE, IEC, DNV, RINA, GL, BV, LR, RMRS, ABS |
FAQ
Yes, we only supply 100% new and original Schneider TSXAEY800 modules.
Q2: How quickly can you ship this module?
We ship within 3 days to 2 weeks, depending on the order size.
Q3: What logistics providers do you use?
We commonly use DHL, FedEx, UPS, and other trusted carriers.
Q4: What if there is a defect or issue?
We support returns within 30 days if the product has quality problems.
Q5: Which signal ranges does the module support?
The TSXAEY800 handles both current (0–20 mA, 4–20 mA) and voltage (±10 V, 0–10 V, 0–5 V, 1–5 V) inputs.
